Heavy Sand Washing Machine /Spiral Sand Washer
US$ 1,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HengPeng
Place of Origin:
China
Model Number:
HP-SWMH
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
30 days
Related Products
-
China Sand Washing Machine & Sand Sieving Machine for Superior Sludge SeparationUS$ 130,000 - 260,000MOQ: 1 Set -
Marine High Buoyancy Pipe Floater for Sand Dredger Rubber Hose Sludge Discharge Pipeline 100-4000mUS$ 50 - 500MOQ: 1 Set
-
Premium Sand Pipeline Gold Recovery Floatation Device - FT100-2000US$ 50 - 300MOQ: 1 Pair
-
High Performance 36-Inch Discharge Rubber Hose for Dredging OperationsUS$ 50 - 500MOQ: 1 Pair
-
150kVA Weichai Engine Diesel Generator Standby Emergency UnitUS$ 7499 - 7500MOQ: 1 Set
Brand Name
HengPeng
Place of Origin
China
Model Number
HP-SWMH
Type
Other, Sand Washing Machine
Certification
CCS BV ISO9001 ZC DNV
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
12 Months Free Warranty, Free Repair
Condition
New
Basic Info.
Model NO.
HP-SWMH
Motor Power
7.5-21 Kw
Wheel Bucket Diameter
3600mm
Warranty
1 Year
After-sales Service
1 Year
Transport Package
Bulk/Container
Trademark
HENGPENG
Origin
China
Production Capacity
200 Sets/Year
Product Description
# Heavy Sand Washing Machine /Spiral Sand Washer in HengPeng Shipyard
About Hengpeng Sand Washing Machine/Cutter Type Dredging Equipment:
1. Hengpeng Product Description:
Hengpeng Sand washing equipment is suitable for sand materials with a high content of clay or a high content of viscous impurities, such as mine tailings, sand mountain tailings etc, with a mud content of less than 30%. Loaded by loaders or trucks, its daily processing capacity is approximately 800m³.
This Hengpeng product is developed based on a sand washing machine product of American JD company in 2000, it is suitable for making domestic construction sand and stone material products. It has a excellent sand washing effect, featuring easy maintenance, stable and excellent performance. Over the past more then ten years it has been widely used for fine material concentration in such areas as gravel pits, mines, building material industry, expressway and high-speed rail sites, mixing stations etc. And it is highly praised by users.
Design and manufacture various models of dredging euipments. all Hengpeng product can be customized according to customer persionalized needs.
With a successful professional design and 35+ years of dredging manufucture production workmanship ability, Hengpeng Shipyard can quickly advise you the type of equipment you need and the suitable one.
Design and manufacture various models of dredging euipments. all Hengpeng product can be customized according to customer persionalized needs.
With a successful professional design and 35+ years of dredging manufucture production workmanship ability, Hengpeng Shipyard can quickly advise you the type of equipment you need and the suitable one.
Hengpeng Sand Washing Machine Features and Advantages:
1. The transmission system is separated from the working water surface, this can greatly avoid the electrical devices and bearings from damage by sand wearing and water pollution, so the equipment does not need has a long service life without the need of maintenance.
2. The sand and stone powder wash away rate is very low, the fineness of the building sand made by this machine is up to the national standards for "building sand" "construction gravel, pebbles ".
3. The company has developed a kind of sand washing machine which is wearable, featuring full hydraulic transmission, high sand washing speed and all-weather operation, the product quality has reached a higher level, please contact us if you are interested to it.
4. Usually , in dredging project the sand dredging vessel pump the sand and water slurry onto land ,where the sand washing machine will separate sand from slurry.If there is other mine, we can also design separation equipment together with the sand washing vessel.
(1) Simple structure with low failure rate.
The sand washing machine structure is simple and reasonable.The impeller drive bearing device is isolated from water and material, the sealing device is novel, and the oil bath type drive device is completely enclosed, which can avoid the damage of bearing caused by water and pollution in shahe river.
(2) Low cost, Reliable quality.
(3) Easy install and maintain and operate.
About Hengpeng Sand Washing Machine Parameters
* all Hengpeng product can be customized according to customer persionalized needs.About Hengpeng Sand Washing Machine Parameters
| Model | Processing capacity m³/h | Wash away rate | Power (kw) |
| HP-XS2600 | 30-60 | 10% | 7.5 |
| HP-XS2800 | 50-90 | 12% | 11 |
| HP-XS3200 | 90-140 | 12% | 15 |
| HP-XST | 200-300 | 10% | 21 |
1. Lifetime Technical Support, provide technical guidance on engineers usage and other aspects according to consumer requirements
2. 24-hour service response mechanism
3. Making an excellent filing of customers for long-term following-up service.
4. All the dredgers can be Customized.
5. Field Installation,commissioning,and training by our engineers
6. Provide professional service and providesolution in a timelymanner.
7. 12 months free warranty, free repair services,.
8. Sending engineers to assemble and test the machine within theperiod as agreed in the contract.
9. Ensure the supply of maintenance spare parts, and shipyard warehouse inventory of dredger/barge parts can quick and efficient supply in a short period of time;
