Help CenterSDVC21-XLP（25A）Variable Voltage Digital Controller for Vibratory Feeder
Related Products
-
SDMC20-S Digital Single-phase AC Asynchronous Motor ControllerUS$ 62 - 69MOQ: 1000 Pieces -
SDMC10-S Digital Low Voltage Brushed DC Motor ControllerUS$ 62 - 69MOQ: 1000 Pieces
-
SDVC35-MRJ Variable Frequency Intelligent Controller for Vibratory FeederUS$ 593 - 659MOQ: 1000 Pieces
-
SDVC35-MRJ Variable Frequency Intelligent Controller for Vibratory FeederUS$ 593 - 659MOQ: 1000 Pieces
-
SDVC31-XL（6A）Variable Frequency Digital Vibratory Feeder ControllerNegotiableMOQ: 1 Piece
CE certificate.
IP Grade: IP67. The controller keeps running well in humid, oily, and dusty environments
Super Wide Input Operation Voltage: The input voltage value to the controller could range from 85 to 400 AC
Automatic Voltage Regulation: The internal digital voltage regulation circuit can reduce feed speed variation caused by mains voltage fluctuation.
Time Adjustable Soft Start: When powered on, the controller will gently increase output from 0 to the preset value to avoid a sudden shake. Soft scan be digitally preset.
Preset Speeds: 4 feed speeds can be preset, stored, and outputted by connecting an external short-circuit signal
Dual Switch Sensor ON/OFF Control: 2 NPN switch sensors or PLCs can be connected to turn on /off the controller.
Photoelectric Sensor ON/OFF Control: The CUH Intelligent Photoelectric Sensor can be connected to turn on/off the controller.
Remote Speed Control: The output Voltage of the controller can be adjusted remotely by an external potentiometer, a PLC, or a 1-5V DC signal.
DC Control Output: The controller can output low voltage DC power associated with the ON/OFF Control of the controller to drive a solenoid or other ext
Lightning Protection: The controller can withstand lightning stroke below 4KV
Overheat Protection: If the internal temperature of the controller is too high, the controller will stop its output to protect itself.
Overcurrent Protection: If the output current exceeds its rated value, the controller will stop its output to protect itself and the load.
Fuse-Short Circuit Protection: If the output of the control is short-circuited, the fuse inside will be blown to protect the control and the load.
Max Adjustable Output Voltage: Max Adjustable Output Voltage can be preset to protect the load from damage caused by too high voltage.
