INDUSTRIAL ALL IN ONE PC WINDOWS 11 PRO SC800M

PC

CPU

Intel® Celeron J4125, 4 Cores, 4 Threads, Base 2.0 GHz, Turbo 2.7 GHz, 4MB Cache, Fanless

CPU Optional

Intel® Celeron J6412, 4 Cores, 4 Threads, Base 2.0 GHz, Turbo 2.6 GHz, 1.5MB Cache, Fanless

CPU Optional

Intel® Core i5-8260U 4 Cores, 8 Threads, Base 1.6 GHz, Turbo 3.9 GHz, 6MB Cache, Fanless

CPU Optional

Intel® Core i5-8365U 4 Cores, 8 Threads, Base 1.6 GHz, Turbo 4.1 GHz, 6MB Cache, Fanless

CPU Optional

Intel® Core i7-8565U 4 Cores, 8 Threads, Base 1.8 GHz, Turbo 4.6 GHz, 8MB Cache, Fanless

CPU Optional

Intel® Core i7-8569U 4 Cores, 8 Threads, Base 2.8 GHz, Turbo 4.7 GHz, 8MB Cache, Fanless

CPU Optional

Intel® Core i5-10210U 4 Cores, 8 Threads, Base 1.3 GHz, Turbo 4.2 GHz, 8MB Cache, Fanless

CPU Optional

Intel® Core i5-10310U 4 Cores, 8 Threads, Base 1.7 GHz, Turbo 4.4 GHz, 8MB Cache, Fanless

CPU Optional

Intel® Core i7-10510U 4 Cores, 8 Threads, Base 1.8 GHz, Turbo 4.9 GHz, 8MB Cache, Fanless

CPU Optional

Intel® Core i7-10610U 4 Cores, 8 Threads, Base 1.8 GHz, Turbo 4.9 GHz, 8MB Cache, Fanless

CPU Optional

Intel® Core i5-1135G7, 4 Cores, 8 Threads, Base 2.4 GHz, Turbo 4.2 GHz, 8 MB Cache, Fanless

CPU Optional

Intel® Core i7-1165G7, 4 Cores, 8 Threads, Base 2.8 GHz, Turbo 4.7 GHz, 12 MB Cache, Fanless

CPU Optional

Intel® N100, 4 Cores, 4 Threads, Turbo 3.3 GHz, 6MB Cache, Fanless

Memory

J4125: 1x DDR4 SODIMM,  Max 8G DDR4

J6412/N100: 1x DDR4 SODIMM,  Max 16G DDR4

Core i5/i7: 2x DDR4 SODIMM, Max 64G DDR4

Storage

1 x M.2 2242/2260/2280 SATA, 1 x SATA(2.5'' SATA ) , 1 x M.2 2280 NVME

Hard Drive Capacity

128GB, 256GB, 512GB, 1TB, 2TB, 4TB, SSD, 500GB, 1TB, 2TB, 4TB HDD Optional

Network

2x 2.5 GbE RJ45 Intel i225V (4 x 2.5GbE RJ45 Intel i225V Optional)

Wireless Network

WIFI/Bluetooth/3G/4G/5G module Optional

I/O Interface

4 x USB2.0 , 2 x USB3.0 (J4125/J6412)
2 x USB2.0 , 4 x USB3.0 (8th/10th/11th generation intel Core i5/i7)

2x DB-9 COM1& COM2, RS232/422/485

1x HDMI/Audio Line-out/ Power Button

1x AT/ATX switch

1 x Extended IO: 4x RS232(4x3 wire COM3&COM4&COM5&COM6), GPIOx10, 1x Remote Switch

2x 8Ω 1W Amplifier out optional

Expansion slot

M.2 3042/3052 3G/4G/5G Module, onboard SIM Card Slot

M.2 2230 WiFi Bluetooth

Watchdog timer

1 to 65535 seconds programmable setting

Operation System

Support Windows® 10/11, WES 10, LINUX, etc.

Support

TPM 2.0

Support

PXE Boot

Support

UUID

LCD panel

Panel size

10.1", 12.1", 15.6", 15", 17", 19",21.5"

Resolution

1024*768, 1280*800, 1280*1024, 1920*1080

Aspect ratio

4:3, 16:9, 16:10

Support Color

16.7M colors

Brightness (cd/m²)

500 nits

Response time

5ms

Contrast ratio

1000:1

View angle

85°/85°/85°/85° (R/L/U/D)

Touch panel

Touchscreen Type

Project Capacitive Touch (10 points)

Touch Interface

USB (RS232 optional)

Touch response time

2ms

Luminousness

90%

Surface Hardness

7H

Working life

>50 million times

Touch options

(5 Wire Resistive Touch Optional)

Power Supply

External Power Supply

AC 100-240V

Working voltage

9-36V DC Wide Voltage with 4PIN Aviation Connector

Power consumption

≤28W

Enclosure

Material

Aluminum Alloy

Color

Grey

VESA mounting

75x75/100x100mm

IP grade

Front panel IP65 waterproof

Operating Environment

Temperature Range

Operating: -20 to 70°C, Storage: -30 to 80°C

Relative humidity

10%~90% @ 30° C, Non-condensing

Vibration

5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis

Packing Details

Accessories

Power adapter, Power cord, Embedded screws, Phoenix terminal

Accessories optional

WIFI module, 3G/4G/5G module, VESA bracket

Other

Mounting (options)

Embedded mounting screws

Wall mounting brackets (optional)

Desk stand holder (optional)

Warranty

2 years warranty

Certificate

CE, FCC, RoHS

10.1"

1280*800

16:10

capacitive/resistance

12.1"

1024*768

4:3

capacitive/resistance

15"

1024*768

4:3

capacitive/resistance

15.6"

1920*1080

16:9

capacitive/resistance

17"

1280*1024

5:4

capacitive/resistance

19"

1280*1024

5:4

capacitive/resistance

21.5"

1920*1080

16:9

capacitive/resistance
