Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN

Shenzhen Beilai Technology Co., Ltd. Verified Business License
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN thumbnail-1
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN thumbnail-2
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN thumbnail-3
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN thumbnail-4
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN thumbnail-5
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN photo-1
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN photo-2
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN photo-3
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN photo-4
Q03UDE PLC Module to OPC UA, MQTT, Modbus RTU, Modbus TCP Protocols Converter With RS485 4G WiFi LAN photo-5
US$ 42.55 - 75 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
BLIIOT
Place of Origin:
China
Model Number:
BL104
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BLIIOT
Place of Origin China
Model Number BL104

Product Description

Modbus TCP/TCP PLC Protocol to OPC UA MQTT Modbus TCP gateway BL104
Item No.: BL104
BL104 support Modbus RTU Modbus TCP PLC to OPC UA/MQTT/modbus multi-protocol converter

  • Basic Version: 2 Serial Ports: BL104

  • P Version: 6 Serial Ports: BL104P

Downlink Supports Modbus RTU Modbus TCP PLC
Uplink Supports OPC UA MQTT Modbus Tcp
Supports SNMP V1/V2
Supports transparent transmission
RJ45 Ethernet ports
RS-485/232 serial ports
Supports OpenVPN
Supports 4G communication
Supports routing functions and cascading switch
Supports remote configuration and firmware upgrade

Detailed Photos


Model List

ModelWANLANCOM(Default
RS485,optional RS232)		WiFi4GGPS
BL104112×××
BL104L112×√×
BL104LG112×√√
BL104W112√××
BL104P116×××
BL104PL116×√×
BL104PLG116×√√
BL104PW116√××


Product Parameters


ParameterDescription
SystemProcessorClock speed 300Mhz
Storage128MB
Flash memory64MB
Power SupplyInput voltageDC 9~36V
Power consumptionNormal: 85mA@12V, MAX: 117mA@12V
WiringAnti-reverse connection
Ethernet PortsSpecification2CH RJ45, 10/100Mbps, adaptive MDI/MDIX
ProtectionESD: ±6kV(Contact), ±8kV(Air)
EFT: 1kV, 5kHz
Serial PortsQTY2CH RS485 or RS232
Baud Rate2400bps-115200bps
Data Bit7, 8
Parity BitNone, Even, Odd
Stop Bit1, 2
ProtectionESD: ±6kV(Contact), ±8kV(Air)
EFT: 1kV, 5kHz
SIM Card SlotQTY1
SpecificationDrawer type slot, support 1.8V/3V SIM/UIM card (NANO)
ProtectionBuilt-in 15KV ESD Protection
USB PortsQTY1CH program downloading, 1CH program debugging
SpecificationMicro USB OTG
ProtectionOver Current Protection
4G(Optional)Antenna QTY1
Antenna typeSMA
L-EGSM/EDGE:900,1800MHz
WCDMA:B1,B5,B8
FDD-LTE:B1,B3,B5,B7,B8,B20
TDD-LTE:B38,B40,B41
L-CEGSM/EDGE:900,1800MHz
WCDMA:B1,B8
TD-SCDMA:B34,B39
FDD-LTE:B1,B3,B8
TDD-LTE:B38,B39,B40,B41
L-AWCDMA:B2,B4,B5
FDD-LTE:B2,B4,B12
L-AUGSM/EDGE:850,900,1800MHz
WCDMA:B1,B2,B5,B8
FDD-LTE:B1,B3,B4,B5,B7,B8,B28
TDD-LTE:B40
L-AFWCDMA:B2,B4,B5
FDD-LTE:B2,B4,B5,B12,B13,B14,B66,B71
CAT-1GSM:900,1800
FDD-LTE:B1,B3,B5,B8
TDD-LTE:B34,B38,B39,B40,B41
GPS(Optional)Antenna QTY1
Antenna typeSMA
Tracking sensitivity> -148 dBm
Plane position accuracy2.5m
ProtocolNMEA-0183 V2.3
WiFi(Optional)Antenna QTY1
Antenna typeSMA
Protocol802.11a/b/g/n(mixed)
ModeClient mode
Signal path2.4G Channel 1 - 13, 5G Channel 36 - 165
SecurityOpen, WPA, WPA2
EncryptionAES, TKIP, TKIPAES
Speed150Mbps(Max)
Transmission distanceOutdoor open area, up to 20 meters
SSIDSupport
IndicatorPWRAlways on when device powered on
Off when device lose power
RUNFlickering when system running
Off when system shutdown
LINKFlickering when Ethernet communication; Always on when 4G or WiFi communication; OFF when Ethernet, 4G, WiFi are all disconnected.
SoftwareInternet ProtocolIPV4, TCP/UDP, DHCP, DNS
IP RetrievingStatic IP/DHCP
TransmissionSupport Transparent Transmission
DNSSupport Domain Name Resolution
ConfigurationPC configuration software, support WIN XP, WIN 7, WIN 8 and WIN 10
Internet CacheTransmitting: 8Kbyte; Receiving: 8Kbyte
Login PackageSupport custom login package
Heartbeat PackageSupport custom heartbeat package
Safety CertificationMTBF≥100,000 hours
EMCEN 55022: 2006/A1: 2007 (CE &RE) Class B

IEC 61000-4-2 (ESD) Level 3

IEC 61000-4-4 (EFT) Level 3

IEC 61000-4-5 (Surge)Level 3
OthersCE, RoHS, FCC
EnvironmentWorking-40~55ºC, 5~95% RH
Storage-40~70ºC, 5~95% RH
OthersShellPlastic
Dimension30mm×83mm×110mm(LxWxH)
IP GradeIP30
Net Weight133g
InstallationDIN-Rail Mounting, Wall-Mounting

Company Profile

Shenzhen Beilai Technology Co., Ltd. specialized in Industrial Ethernet I/O Modules, IoT Gateways, 4G RTU, 4G Industrial VPN Routers, Industrial Computer. OEM ODM services offered.
