S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN

S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN thumbnail-1
S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN thumbnail-2
S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN thumbnail-3
S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN thumbnail-4
S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN thumbnail-5
S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN photo-1
S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN photo-2
S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN photo-3
S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN photo-4
S7-200 S7-300 FX2N FX3U FX5U To  MQTT Protocol Translation Gateway With RS485/4G/WIFI/GPS/LAN photo-5
US$ 42.55 - 75 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
BLIIOT
Place of Origin:
China
Model Number:
BL102
Contact Supplier Request Quote Chat Now
Shenzhen Beilai Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BLIIOT
Place of Origin China
Model Number BL102

Product Description

PLC to MQTT Industrial IoT Protocol Gateways BL102

Item No.: BL102
BLIIoT BL102 Industrial IoT Protocol Gateways get data from your plc based devices to your MQTT clients. Beilai BL102 IoT gateway supports Siemens, Mitsubishi, Omron, Delta, and other PLC protocols converting to MQTT protocol. The PLC to MQTT gateway supports PLC remote monitoring, PLC remote programming, PLC remote debugging, PLC remote upload and download, PLC remote control, PLC data acquisition, PLC remote communication.

  • Basic Version: 2 Serial Ports: BL102

  • P Version: 6 Serial Ports: BL102P


Downlink Supports PLC protocol
Uplink Supports MQTT
Supports SNMP V1/V2
Supports transparent transmission
RJ45 Ethernet ports
RS-485/232 serial ports
Supports OpenVPN
Supports 4G communication
Supports routing functions and cascading switch
Supports remote configuration and firmware upgrade

Detailed Photos


Model List

Model WAN LAN COM(Default
RS485,optional RS232)		 WiFi 4G GPS
BL102 1 1 2 × × ×
BL102L 1 1 2 × √ ×
BL102LG 1 1 2 × √ √
BL102W 1 1 2 √ × ×
BL102P 1 1 6 × × ×
BL102PL 1 1 6 × √ ×
BL102PLG 1 1 6 × √ √
BL102PW 1 1 6 √ × ×

Product Parameters

 Parameter Description
System Processor Clock speed 300Mhz
Storage 128MB
Flash memory 64MB
Power Supply Input voltage DC 9~36V
Power consumption Normal: 85mA@12V, MAX: 117mA@12V
Wiring Anti-reverse connection
Ethernet Ports Specification 2CH RJ45, 10/100Mbps, adaptive MDI/MDIX
Protection ESD: ±6kV(Contact), ±8kV(Air)
EFT: 1kV, 5kHz
Serial Ports QTY 2CH RS485 or RS232
Baud Rate 2400bps-115200bps
Data Bit 7, 8
Parity Bit None, Even, Odd
Stop Bit 1, 2
Protection ESD: ±6kV(Contact), ±8kV(Air)
EFT: 1kV, 5kHz
SIM Card Slot QTY 1
Specification Drawer type slot, support 1.8V/3V SIM/UIM card (NANO)
Protection Built-in 15KV ESD Protection
USB Ports QTY 1CH program downloading, 1CH program debugging
Specification Micro USB OTG
Protection Over Current Protection
4G(Optional) Antenna QTY 1
Antenna type SMA
L-E GSM/EDGE:900,1800MHz
WCDMA:B1,B5,B8
FDD-LTE:B1,B3,B5,B7,B8,B20
TDD-LTE:B38,B40,B41
L-CE GSM/EDGE:900,1800MHz
WCDMA:B1,B8
TD-SCDMA:B34,B39
FDD-LTE:B1,B3,B8
TDD-LTE:B38,B39,B40,B41
L-A WCDMA:B2,B4,B5
FDD-LTE:B2,B4,B12
L-AU GSM/EDGE:850,900,1800MHz
WCDMA:B1,B2,B5,B8
FDD-LTE:B1,B3,B4,B5,B7,B8,B28
TDD-LTE:B40
L-AF WCDMA:B2,B4,B5
FDD-LTE:B2,B4,B5,B12,B13,B14,B66,B71
CAT-1 GSM:900,1800
FDD-LTE:B1,B3,B5,B8
TDD-LTE:B34,B38,B39,B40,B41
GPS(Optional) Antenna QTY 1
Antenna type SMA
Tracking sensitivity > -148 dBm
Plane position accuracy 2.5m
Protocol NMEA-0183 V2.3
WiFi(Optional) Antenna QTY 1
Antenna type SMA
Protocol 802.11a/b/g/n(mixed)
Mode Client mode
Signal path 2.4G Channel 1 - 13, 5G Channel 36 - 165
Security Open, WPA, WPA2
Encryption AES, TKIP, TKIPAES
Speed 150Mbps(Max)
Transmission distance Outdoor open area, up to 20 meters
SSID Support
Indicator PWR Always on when device powered on
Off when device lose power
RUN Flickering when system running
Off when system shutdown
LINK Flickering when Ethernet communication; Always on when 4G or WiFi communication; OFF when Ethernet, 4G, WiFi are all disconnected.
Software Internet Protocol IPV4, TCP/UDP, DHCP, DNS
IP Retrieving Static IP/DHCP
Transmission Support Transparent Transmission
DNS Support Domain Name Resolution
Configuration PC configuration software, support WIN XP, WIN 7, WIN 8 and WIN 10
Internet Cache Transmitting: 8Kbyte; Receiving: 8Kbyte
Login Package Support custom login package
Heartbeat Package Support custom heartbeat package
Safety Certification MTBF ≥100,000 hours
EMC EN 55022: 2006/A1: 2007 (CE &RE) Class B

IEC 61000-4-2 (ESD) Level 3

IEC 61000-4-4 (EFT) Level 3

IEC 61000-4-5 (Surge)Level 3
Others CE, RoHS, FCC
Environment Working -40~55ºC, 5~95% RH
Storage -40~70ºC, 5~95% RH
Others Shell Plastic
Dimension 30mm×83mm×110mm(LxWxH)
IP Grade IP30
Net Weight 133g
Installation DIN-Rail Mounting, Wall-Mounting
