Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > 4.5kw Single Phase 220v Diesel Generator 186FA Diesel Engine
4.5kw Single Phase 220v Diesel Generator 186FA Diesel Engine
US$ 430 - 440
MOQ: 10 Sets
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2017
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
30 days
Related Products
-
4.5KW Three Phase 380V Open Frame Diesel Generator With 186FA Engine & Pure Copper MotorUS$ 460 - 470MOQ: 10 Sets -
4.5kw Dual Power Diesel Generator 186FA Diesel EngineUS$ 490 - 500MOQ: 10 Sets
-
4.5KW Single Phase 220V Silent Diesel Generator With 186FA EngineUS$ 540 - 550MOQ: 10 Sets
-
4.5kw Three Phase 380v Silent Diesel GeneratorUS$ 575 - 585MOQ: 10 Sets
-
4.5kw Dual Power Silent Diesel GeneratorUS$ 600 - 610MOQ: 10 Sets
| Model | DG6500LE |
| Frequency[Hz] | 50 60 |
| Voltageg[V] | 110/220.115/230.120/240 |
| Rated Power( KW) | 4.5 5.0 |
| Max. Power(KW) | 5 5.5 |
| Rated Output Current（A ) | 19.5 22 |
| DC Output | 12V 8.3A |
| Phase | Single phase |
| Excitation Method | Brush self-excitation |
| Power FactorΦ | 1.0(0.8) |
| Insulation Class | F |
| Fuel Tank Capaciity[L] | 12.5 |
| Engine Model | 186FA |
| Start Method | Electric start |
| Engine Type | Single cylinder,4 stroke,air-cooled, vertical |
| Bore*Strokke[mm] | 86*72 |
| Displacement | 0.418L |
| Compression Ratio | 19.5：1 |
| Speed[rpm] | 3000 3600 |
| Power [Kw] | 5.8 6.6 |
| Oil Capacity[L] | 1.65 |
| Fuel Consumption[g/kwh] | ≤275 ≤280 |
| Fuel No. | Diesel: 0#(Sumner), -10#(Winter) Use No. 0 diesel in summer, and use No. -10 or No. -20 diesel in winter. |
| Oil No. | SAE10W30 (CD grade or above) uses CD or above grade 15W-40 oil (or SAE equivalent grade oil) |
| Optional | ATS |
| Remote Control | |
| Intelligent digital display panel | |
| Size [mm] (L*W*H) | R720*485*615/25mm S700*485*600/ 35mm S 740*505*620 |
| Packing Size [mm] (L*W*H) | R740*500*635/25mmS 710*500*620/ 35mmS760*515*630 |
| Net Weight/Gross Weight[Kg] | R106/25mm S112/35mmS118 R109/25mmS/115/35mm S121 |
