Li-Battery Electric Railway Grinding Machine/ Rail Grinder
Negotiable
MOQ: 2 Bags (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
linkage
Place of Origin:
China
Model Number:
LJ-LGF2001
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Internal Combustion Rail Waist / Rail Web Grinding Machine / GrinderNegotiableMOQ: 2 Bags -
Hydraulic Rail Tamping Machine for Railway Ballast TampingNegotiableMOQ: 2 Bags
-
Automatic Remote Control Rail Tamping MachineNegotiableMOQ: 2 Bags
-
Hydraulic Rail Turnout Tamping MachineNegotiableMOQ: 2 Bags
-
Portable Rail Ballast TamperNegotiableMOQ: 2 Bags
Brand Name
linkage
Place of Origin
China
Model Number
LJ-LGF2001
Product Description
72V Intelligent Lithium Battery Profiling Grinding Machine*The depth of the feed, the real-time battery power digital display, the operator is clear at a glance
*Dual control system, both electronic feed and mechanical operation feed
*Electronic feed, the feed precision is adjustable, realize the dual purpose of primary grinding and precise grinding
*Preset the warning feed depth for grinding to prevent excessive grinding and cause grinding accidents
*Super endurance capability, can work continuously for 1 hour *The whole machine is waterproof and can be used below minus 30 ℃
Specification
Model |
LJ-LGF2001 |
Type |
Electric Rail Grinding Machine |
Material |
Aluminium |
Operating speed |
4500r/min |
Rated power |
5Kw (brushless DC motor) |
Grinding wheel feed accuracy |
≤0.1 mm |
Grinding wheel size |
150*55*75x4-M8 mm (outer diameter×inner diameter×thickness) |
Maximum tilt range of the grinding wheel |
90° in one direction |
Operating temperature requirements |
-30℃ to 45℃ |
Grinding wheel type |
resin thick-walled cup-shaped grinding wheel |
Battery pack capacity |
21Ah |
Rated voltage of battery pack |
72V |
Weight |
70Kg |
Profiling function |
realize profiling grinding of the outer edge contour of different types of rails |
Endurance capability(one charge) |
thermit welding grind around 8 welds; laser welding grind around 10 welds
|
Grinding wheel feeding mode |
Dual control system, which can feed both mechanically and electronically |
Electronic feed |
It is divided into three gears for key switching and operation. First gear: fine grinding, unit feed 0.1mm
Second gear: initial grinding, unit feed 0.3m
Third gear: initial grinding, unit feed 0.5mm
|
