2 Axles Long Distance Enclosed Car Carrier Trailers

2 Axles Long Distance Enclosed Car Carrier Trailers thumbnail-1
2 Axles Long Distance Enclosed Car Carrier Trailers thumbnail-2
2 Axles Long Distance Enclosed Car Carrier Trailers thumbnail-3
2 Axles Long Distance Enclosed Car Carrier Trailers thumbnail-4
2 Axles Long Distance Enclosed Car Carrier Trailers thumbnail-5
2 Axles Long Distance Enclosed Car Carrier Trailers photo-1
2 Axles Long Distance Enclosed Car Carrier Trailers photo-2
2 Axles Long Distance Enclosed Car Carrier Trailers photo-3
2 Axles Long Distance Enclosed Car Carrier Trailers photo-4
2 Axles Long Distance Enclosed Car Carrier Trailers photo-5
US$ 88888 - 99999 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
FOCUS
Place of Origin:
China
Model Number:
focus car trailer 023
Contact Supplier Request Quote Chat Now
Henan Focus Vehicles Co.,ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name FOCUS
Place of Origin China
Model Number focus car trailer 023
Material Steel
Size 16150mm*3000mm*4200mm
Certification DOT
Type Semi-Trailer
OEM No. FOCUS 025
Max Payload 12T
Car Carrier Semi-trailers designed for pallet structure are used for loading parts of semi-trailers. Besides cars, can also carry minibus, Business commercial vehicles, Jeeps and other passenger cars. A semi-trailer is a trailer that is placed behind the center of gravity of the vehicle (when the vehicle is loaded evenly) and is equipped with a connecting device that passes the horizontal or vertical force to the tractor.

According to the body structure of the car, we can divide the car into three structures, such as skeleton, semi-closed and all closed. According to the rear bridge structure of the car, we can divide the car into two axle single tire, double axle and double tire.
    The advantage of 2Axles Long Distance Enclosed Car Carrier Trailer1. Light structure; the platform uses the hydraulic cylinder to open, stable lifting;
    2. Safe and convenient operation: all loading and unloading platform lifting control operation is reliable, can be clearly observed, accurate operation.
    3. Suspension system: the unique type of leaf spring mounted suspension system, variable cross-section leaf spring, good ride performance;
    4. We use the famous brand parts, such as JOST brand kingpin and landing legs, WBACO braking valve.
    The specification of 2Axles Long Distance Enclosed Car Carrier Trailer

    Overall Length

    16150mm

    Overall Width

    3000mm

    Overall Height

    4200mm

    Payload

    6-8 cars

    Main Construction

    Overall skeletal structure, Hydraulic lifting double-deck, Telescope rear ladder

    I Beam &Chassis

    Overall loading chassis; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes.

    Axle

    2 axles

    L1 12 ton

    Suspension

    German design mechanical suspension

    Hydraulic

    4 sets Hydraulic Cylinder

    Leaf Spring

    8-piece leaf spring.

    King Pin

    JOST brand 2” Bolt-in King Pin

    Landing Gear

    JOST brand Two-speed, manual operating, heavy duty landing gear

    Wheel Rim

    7.0-20 steel wheel rim, 9 pieces

    Tire

    Single tire, 9.00R20 with one spare tire, 9 pieces

    Spare Tire

    One sets of spare tire

    Braking System

    WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks

    Painting

    Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint

    Accessories

    One standard toolbox


    Product Tags: Car Carrier Trailers , 2 Axles Long Distance car trailer , Enclosed Car Carrier Trailers , logistic trailers , car semi trailer , trailers
