Product Details
Brand Name: | FOCUS | Place of Origin: | China | Model Number: | FOUCUS 085 |
Material: | Steel | Size: | 13,750*3,000*3,300mm | Certification: | DOT |
Type: | Semi-Trailer | OEM No.: | 085 | Max Payload: | 100T |
Product Description
The 8-axle flatbed trailer represents an ideal solution for the transportation of a wide range of heavy-duty cargo and equipment. With its robust design and exceptional load-bearing capacity, this specialized trailer is tailor-made for the efficient transport of diverse items such as heavy machinery, oversized objects, highway construction equipment, large tanks, power station machinery, and a variety of steel materials.
In conclusion, the 8-axle flatbed trailer is a versatile and dependable choice for transporting a wide array of heavy equipment and materials. Its rugged construction and exceptional load-bearing capabilities make it an indispensable asset for industries that require the safe and efficient movement of oversized and heavyweight cargo on highways and beyond.
SPECIFICATION
ITEM | DESCRIPTION |
Dimensions(L*W*H) | 13,750*3,000*3,300mm |
Wheelbase | 8,200+1,310+1,310+1,310mm |
Loading Capacity | 100T |
Trailer Weight | 13,000kg |
Main beam | Q345 steel; The height of the beam is 635mm |
Flange & Web | 146 mm, wide/ 20 mm, up/ 20mm, down web 12mm |
Side Frame | 250 ×78×7 mm, channel steel |
King Pin | 2” (50mm) or 3.5” (90mm) traction pin |
Floor | 4mm diamond steel plate |
Painting | Sandblasting, SA 2.5; 50 μm Primer Epoxy Zinc-Rich 70 μm Finish Acrylic Urethane |
suspension | Mechanical suspension with 10/10/10/10 |
Axle | 8*13ton FUWA brand |
Tire | 12R22.5 ×32 Nos |
Rim | 9-22.5 ×32 Nos. |
Brake valve | Dual Airline, ABS, WABCO |
Landing Gear | JOST brand two-speed, Manual operating Heavy duty 28ton |
Ladder | Hydraulic |
Toolbox | 1 pc |
Spare tire | YES |
Electrical System | One unit of jaeger Poway, 24v 7-pin iso 1185 Turn signal, brake light, reverse & reflector, side lamp, etc. |
