4X2 Dongfeng 5Tons Van Trucks

4X2 Dongfeng 5Tons Van Trucks thumbnail-1
4X2 Dongfeng 5Tons Van Trucks thumbnail-2
4X2 Dongfeng 5Tons Van Trucks thumbnail-3
4X2 Dongfeng 5Tons Van Trucks thumbnail-4
4X2 Dongfeng 5Tons Van Trucks thumbnail-5
4X2 Dongfeng 5Tons Van Trucks photo-1
4X2 Dongfeng 5Tons Van Trucks photo-2
4X2 Dongfeng 5Tons Van Trucks photo-3
4X2 Dongfeng 5Tons Van Trucks photo-4
4X2 Dongfeng 5Tons Van Trucks photo-5
US$ 10000 - 99999 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
FOCUS
Place of Origin:
China
Model Number:
FOCUS-FREEZER 022
Contact Supplier Request Quote Chat Now
Henan Focus Vehicles Co.,ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name FOCUS
Place of Origin China
Model Number FOCUS-FREEZER 022
Material Steel
Size 6995x2310x2570 mm
Certification DOT
Type Full Trailer
OEM No. focus024
Max Payload 4895KGS

  • Our company is appointed by the Ministry of Industry and Information of China which is a manufacturer for producing all kinds of special trucks, and the van truck is one of our trucks. It consists of chassis, insulation van and refrigerated box. With sealed insulation material, it can deliver different kinds of goods such as meat, fish, seafood, medicines, etc.

The Advantage of 4X2 Dongfeng 5Tons Van Truck1. With GRP (Glass Reinforced Plastic Fiber) outside and PU foam inside, the goods can be stored well.
2. With lighter material, it is convenient and flexible when transporting.
3. With sealed structure and insulation material, it is anti-corrosion and anti-pollution.
4. With sandwich panel used and 50-80mm thermal insulation layer,  it offers a very good thermal insulation performance.
5. The van size is optional according to the goods transported such as rear double-open or side-open box model.
6. The refrigerated box brand is optional such as American CARRIER, THERMO KING, South Korea hanya, China Songhan, hanxue, etc.
7. The Temperature can be ranged from 0° C ~ -20° C which can satisfy different customers’ requirement.
8. With simple structure for refrigerated box, convenient operation, reliable working, low energy consumption, large capacity, low noise and easy installation and other advantages, the van truck is popular on the special truck market.
The Specification of  4X2 Dongfeng 5Tons Van Truck

Item No.

Parameters

Overall Dimension

6995x2310x2570 mm

Gross Vehicle Weight

7345kg

Curb Weight

3550kg

Loading Weight

4895Kg

Wheel Base

3800mm

Front/rear Tread

1120/2075 mm

Approach/Departure Angle

21/20degree

Front Axle

2850kg

Rear Axle

4645kg

Gearbox

LC5T26, 5 speed, manual control.

Engine

4DX22-110, Diesel Engine, 4 in-line cylinder

Engine horsepower

108HP EURO II

Displacement

3.66 L (Diesel)

Full loading Fuel
Consumption Rate

Maximum 215 g/kW.h

Max Driving Speed

90 km/h

Cabin

2 Passenger allowed

Tire

8.25-16 LT (7 pieces)

Carriage Body

Size:

5100x2100x1400mm

Body Material

Strong Fiberglass Inner and Outer Wall,
with 8cm Middle Polyfoam Insulation.

Refrigerator

High Quality Hanxue Refrigerator, Lowest Cooling Temperature negative 18 centi-degree (negative 608 Fahrenheit degree)

LOGO

Company Logo or any advertisement can be printed on the carriage body according to the customer's design.



    Product Tags: 5Tons Van Trucks , 4X2 Dongfeng 5Tons Van Trucks , van truck , van box truck , logistic truck , vehicle
