Water Injection or Gas Filled Packer for Grouting in Hydraulic Geological Mines

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port TianJin
Payment TermsT/T Other
Delivery Detail1 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	AOXING		Place of Origin	China
Model Number	40-1000mm

Product Description

APPLICATIONS:
1.      Pressure Grouting in Fractured or Unconsolidated Borehole or Rock Formations
2.      Water Infusion for Dust Control in Coal Mines
3.      Methane Gas Control and Collection in Mines
4.      Sealing Elements in Soil or Boreholes
5.      Water Sampling Testing
6.      Hydraulic Fracturing Testing
7.      Permeability Testing
8.      Quality Control Testing of Tubes
9.      Bore-Hole Fluid Sampling,
10.   Bore-Hole Wall Impression Testing
11.   Industrial Piping Hydro-Testing,
12.   Water Wells Repair
13.   Aquifers Monitoring

MAIN SPECIFICATOIN

Sealing hole diameter 30-2000mm (can be processed according to user requirements)

Working pressure 1-8MPa (can be processed according to user requirements)

Working flow: 3-4.5 tons per hour

Hole sealing depth 1-8000m

SIZE	I.D(mm)	O.D(mm)	Expansion Range(mm)	Aperture(mm)	W.P(Mpa)	T.P(Mpa)	B.P(Mpa)
φ16-2	16±0.5	30±1.5	50 +8/-2	40	8	16	32
φ16-4	16±0.5	36±1.5	50 +8/-2	40	20	30	40
φ19-2	19±0.5	36±1.5	60 +8/-2	45	8	16	32
φ19-4	19±0.5	40±2.0	60 +8/-2	45	20	30	40
Φ22-2	22±0.5	39±2.0	80 +8/-4	50	6	12	24
Φ22-4	22±0.5	45±2.0	80 +8/-4	50	20	30	40
Φ25-2	25±0.5	42±2.0	90 +8/-4	65	6	12	24
Φ25-4	25±0.5	48±2.0	85 +8/-4	55	16	24	32
Φ32-2	32±0.5	50±2.0	90 +8/-4	60	6	12	24
Φ32-4	32±0.5	54±2.0	90 +8/-4	60	16	24	32
Φ38-2	38±0.5	55±2.0	95 +8/-4	65	5	10	20
Φ38-4	38±0.5	60±2.0	95 +8/-4	65	16	24	32
Φ45-2	45±0.5	63±2.0	100 +8/-4	75	4	8	16
Φ45-4	45±0.5	69±2.0	100 +8/-4	75	16	24	32
Φ51-2	51±0.5	69±2.0	110 +8/-4	90	4	8	16
Φ51-4	51±0.5	75±2.0	110 +8/-4	90	16	24	32
Φ64-2	64±0.5	84±2.0	120 +8/-4	100	3	6	12
Φ64-4	64±0.5	90±2.0	120 +8/-4	100	8	12	16
Φ76-2	76±0.5	94±2.0	130 +8/-5	110	3	6	12
Φ76-4	76±0.5	99±2.0	130 +8/-5	110	8	12	16
Φ89-2	89±0.5	109±2.0	140 +8/-5	130	3	6	12
Φ89-4	89±0.5	114±2.0	140 +8/-5	130	8	12	16
Φ102-2	102±0.5	122±2.0	160 +8/-5	150	3	6	12
Φ102-4	102±0.5	128±2.0	160 +8/-5	150	8	12	16
Φ127-2	102±0.5	141±2.0	160 +8/-5	180	3	6	12

Note: To save your time, it is important to know following basic information when choosing the rubber hose

1) Usage:

2) Borehole Diameters:

3) Gland Rubber Sleeve Length (if any requirement):

4) Single or double packer request:

5) Steel joint pipe length (Straddle zone length if any request in double packer):
