ADG749BKSZ Analog Switch/multiplexer ADI Original Stock

explain

ADG749 is a single-chip CMOS SPDT switch. The switch is designed on a submicron process, providing low power consumption but high switching speed, low resistance, and low leakage current.

The ADG749 can operate within a single power range of 1.8 V to 5.5 V, making it an ideal choice for battery powered instruments and analog equipment companies for the next generation of DADCs and ADCs.

Each switch of ADG749 has good conductivity in both directions when turned on. ADG749 shows a switching action before interruption. Due to advanced submicron technology, it can achieve a bandwidth of -3dB greater than 200 MHz.

ADG749 has a 6-lead SC70 package.

feature

1.8V to 5.5V single power supply

5 Ω (maximum) conduction resistance

0.75 Ω (typical) Resistance flatness

Car temperature range: -40 ° C to+125 ° C

-3 dB bandwidth>200 MHz

Railway on railway operation

6-lead SC70 package

Quick switching time

TON=12 ns

TOFF=6 ns

Typical power consumption (<0.01 μ W)

TTL/CMOS compatible

application

Battery powered system

communication system

Sampling and retention system

Audio signal routing

Video switching

Replace the mechanical reed relay
