[scope of application]: used to determine the breaking strength, extension at break, tear, peeling, jacking, joint slip and joint of various textiles, nonwovens, leather, rubber, metals, etc.
Testing of mechanical properties such as seam strength, slippage, elastic recovery and so on. It has various testing functions, such as fixed speed, positioning shift, fixed time, fixed load, fixed extension and so on.
[meet the criteria]:
Breaking strength (strip method): GB/T3923.1/2;ISO13934.1/2; ASTM D5035
Sampling method: national Standard / T3923.2 ISO13934.2; American material Test Association D5034
Tear strength (tongue tear): GB/T3917.2;ISO13937.2; American Materials Test Association D2261
(ladder tear): GB/T3912.3;ISO9074.4;ASTM D5587; ISO9073.3/4
Seam slip: GB/T13772.1/2/3;ISO13936.1/2;ASTM D434
Peeling strength: FZ/TO1085; ASTM D2724 / 3936 / AATCC 136 / FZ / T80007.1 / FZ / T01010 / FZ / T60011
Steel ball top break: GB/T19976;FZ/T01030;ISO3303;ASTM D3787 ≤ 6796
Flexible reply: FZ/T70005;FZ/T70006;BS 4952
Single yarn strength: GB/T3916/14344;ISO2062; ASTM D2256
Other standards: GB/T4689.6;GB/T13763;GB/T13773;GB/T14800;GB/T15788
GB / T16989; FZ / T01031; FZ / T20019; FZ / T60005; FZ / T60006;
FZ/T70007;ISO13935.1/2 Standard and ASTM D1683 Standard American Materials Test Association D4964
ASTM D5733/5735;BS3320;XF633
[Technical Indicators]
1. Force range: 50 kg, 100kg, 250kg, 500kg, 1000kg; Full scale 1 ~ 100%; (Optional)
2. Measuring accuracy: ≤ ± 0.2% FS;
3. Drawing speed: 1 ~ 500mm / min (arbitrary setting);
4. Recovery speed: 1 ~ 500mm / min (arbitrary setting);
5. Sampling frequency: > 1000 times / s;
6. Extension resolution: ≤ 0.01 mm;
7. Effective movement: 600 mm (Air Jig) 700 mm (Hand Jig);
8. Power supply: AC220V + 10% / 50Hz;
9. Power: 500 w;
10. External dimensions: 665 x 450 x 1640 mm;
11. Net weight: 175 Kg.
[Instrument characteristics]:
1. The A / D Changer is controlled by 32 bit industrial MCU and produced by American AD Company, which has strong anti-interference performance, fast data processing and transmission, and has reached the advanced level of foreign countries.
2. The dynamic sampling frequency is more than 1000 times per second, and the peak value of each data can be captured effectively and correctly in the test process.
3. LCD touch screen operation, full Chinese menu, built-in printer direct output report, easy to operate;
4. Computer online control, dynamic tracking instrument working status; Transmission of test data and real-time display of tensile curve;
5. Manual clamping, AC servo drive, precision screw drive, silent operation;
6. Built-in automatic digital force calibration system;
7. Test function integration design, open data connection interface, to achieve a multi-purpose machine;
8. Units of force value: CN, N, Kg and Ib, etc. Free conversion;
9. With overload, overtravel and overvoltage protection, so that the instrument running safe and reliable.
