GSM Tracker 4 Channel Mobile DVR 3G HDD GPS MDVR with Paypal
MDVR Functions
The MDVR allows you to track and view your vehicles in REAL TIME via live video camera streaming from up to 4 cameras on your truck, car ,bus,taxis, police cars, excavators, petorl trucks, law enforcement vehicles, and other various types of vehicles with people counting,RFID card reader,fuel consumption sensor,LED display functions etc.
Using the Internet, GPS, and Mobile CCTV technology, you can now view your vehicles, drivers and cargo from your office, wherever they are in the country. Our cloud-based Control Room software also allows you track your fleet, identifying speed, location, fuel-level and many more.
Vehicle Tracking that lets you SEE the FULL picture.
Main Features
1) 4CH, Support 4 cameras
2) H.264 compression format
3) 2.5“ SATA 1TB Hard disk
4) GPS tracking
5) 3G remote control
7) 4 alarm input, 1 alarm output
8) 2 way intercom
9) Patent UPS continuously working to protect data upon sudden power-off
Specification
Item | Description | |
OS | Linux | |
Graphics Operation Interface | System parameters can be set through external display and remote controller | |
Security Management | 2-level management for user password, administrator password, supporting encrypted transmission | |
Video and Preview | Video Input, Output | 4-channel video input, 1channel video output; 1.0Vp-p, 75Ω |
OSD | Character superposition function, information superposition of time and date, device ID and GPS, etc. | |
Video Compression Format | Compression coding. Applying Hisilicon hi-performance processor. | |
Dual-Stream | Supported | |
Preview Function | Preview of 1-channle, 4-image stitching, supporting full screen triggered by event and switching of stitched images | |
Frame Rate | PAL: 100 frames/s, up to 25 frames/s per channel; NTSC: 120 frames/s, up to 30 frames/s per channel | |
Resolution | CIF, HD1 and D1 for selection, supporting 2 channels of D1+ 2 channels of CIF at the most | |
Quality | Grade 1 to grade 5 for selection (descending) | |
Bit Rate | CIF: 256Kbps ~ 1.5 Mbps, 8-level bit rates for selection HD1: 600Kbps ~ 2 Mbps, 8-level bit rates for selection D1: 800Kbps ~ 3Mbps, 8-level bit rates for selection | |
Audio | Audio Input, Output | 4-channel input, 1-channel output |
Compression Format | G.726 coding | |
Recording | Storage Medium | Supporting one 2.5” hard drive and one SD card, which supports up to 32G, supporting data redundancy storage technology; |
File Format/ System | ASF/FAT32 | |
Video Strategies | Recording at startup by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording | |
Video Search | Searching by time, type, storage device and other conditions | |
Video Playback | Supporting playback on local device, supporting synchronous playback of up to 4 channels and analysis on vehicle information in the files | |
Supporting fast forward, fast backward, play and pause, supporting fast forward and fast backward at 2x, 4x, 8x and 16x speed, supporting file play from selected time | ||
Alarm | Alarm Input/ Output | 6-channel on/off signal alarm input, 1-channel on/off signal alarm output |
Alarm Recording | Prerecording function 15 seconds before alarm, duration of recording after alarm can be adjusted from 30s ~ 30mi |
