Diffuser
- 999999 Piece / Pieces per Month
- shenzhen
- T/T
Product Details
Place of Origin: | China | Material: | glass/ quartz/eagle XG | Size: | 10X10X0.7MM / 50X50X1.0MM / 100X100X2MM |
Use: | It is used for uniform diffusion of light and modulation of spot size |
Product Description
High Transparency: Glass diffusers typically have a high light transmittance rate, ensuring effective light transmission.
Uniform Diffusion: Through special surface treatments, such as micro-structure etching, glass diffusers can uniformly diffuse light.
Temperature Resistance: Glass materials have good heat resistance, making them suitable for use in high-temperature environments.
Chemical Corrosion Resistance: Glass is not easily subject to chemical corrosion, making it suitable for use in a variety of environments.
High Durability: Compared to plastic materials, glass diffusers are more resistant to wear and have a longer service life.
Customizability: Different diffusion effects and intensity distributions can be customized as needed, such as flat-top, 1/cosnθ intensity distributions, and square or circular diffusion curves.
High-End Lighting: Due to their high transparency and uniform diffusion characteristics, glass diffusers are suitable for high-end lighting systems, such as indoor and outdoor lighting.
Display Technology: In flat panel TVs, monitors, and other display devices, glass diffusers are used to provide uniform backlighting, improving display quality.
Automotive Lighting: Used in automotive headlight covers or in-car lighting systems to enhance lighting effects and reduce glare.
Advertising Industry: In advertising light boxes and display stands, diffusing light makes the advertising content brighter and more eye-catching.
Construction Industry: Used in architectural lighting, skylights, and light wells, to achieve a naturally soft indoor lighting effect.
Medical Equipment: In medical lighting systems, to ensure even and soft lighting during surgery and examination processes.
3D Sensing: In the TOF module of 3D cameras, as a core optical element, it helps to accurately measure depth information.
Mini-LED Backlighting: In Mini-LED backlight technology, the use of glass diffusers with patterned dots can improve local dimming effects, brightness uniformity, and color uniformity, while reducing the number of LEDs.
Technical index
Divergence type | Gaussian divergence/flat-top divergence |
Material | eagleXG, white glass, quartz |
Surface requirements | 60-40(S/D) ISO99211 |
Divergence half Angle (falling along 60% intensity) | 0.5-8 degrees |
Angle tolerance range | +-0.3 degrees |
Coating | AOI=0~30 degree 420nm-680nm,Ravg<0.5%;420nm-680nm,Ravg<0.5%; |
Anti-laser loss threshold | >200W/mm2, |
Size | 60x60x0.7mm, 80x80x0.7mm, etc., the size can be customized cutting according to requirements, the maximum size can be 150x150mm |
