Sintered Wire Mesh 5-Layer Composite Plate 150 Micron for Gas Diffusion
Product Spotlights
5-layer sintered wire mesh composite plate with 150 micron pore size for efficient gas diffusion. High temperature and corrosion resistance, low pressure drop, customizable dimensions. Over 20 years of manufacturing experience with global export to 15+ markets. Easy to clean and regenerate, offering long service life for demanding applications.
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Stainless steel (304/316L available)
Application:
Other, Gas diffusion
Layer Count:
5-layer
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin shanghai qingdao
Delivery Detail:
1 days
Related Products
-
Sintered Wire Mesh Filter Disc 100 Micron for Food and Beverage FiltrationNegotiableMOQ: 1 Piece -
Sintered Wire Mesh 316 Stainless Steel 50 Micron for Chemical ProcessingNegotiableMOQ: 1 Piece
-
Sintered Wire Mesh Filter, 100 Micron, 316L, 2.0mm Thickness, 1 Year WarrantyNegotiableMOQ: 1 Piece
-
316L Sintered Wire Mesh, 5 Micron Pore Size, 2mm Thickness for Industrial FiltrationNegotiableMOQ: 1 Piece
-
Sintered Wire Mesh for Liquid Filtration in Chemical Processing, 304 SS, 10 MicronNegotiableMOQ: 1 Piece
Material
Other, Stainless steel (304/316L available)
Application
Other, Gas diffusion
Layer Count
5-layer
Pore Size
150 micron
Shape
Plate
Thickness
Customizable (1.0 - 5.0 mm)
Operating Temperature
Up to 600°C (depending on material)
Porosity
30% - 40%
Surface Finish
Sintered, non-woven structure
As a leading manufacturer since 1998, Anping County Boli Hardware Wiremesh Products Factory specializes in precision-engineered wire mesh solutions. Our sintered wire mesh 5-layer composite plate with 150 micron rating is specifically designed for high-performance gas diffusion applications. Combining superior mechanical strength with uniform pore distribution, this product ensures consistent gas flow and exceptional filtration efficiency, meeting the demands of industries such as chemical processing, energy, and environmental protection.
Key Features & Technical Specifications:
- 5-Layer Composite Structure: Each layer is precisely sintered together to form a rigid, monolithic plate that resists delamination and deformation under high pressure and temperature.
- 150 Micron Pore Size: Optimized for gas diffusion and fine particle retention, ensuring uniform gas distribution across the entire surface.
- High Temperature & Corrosion Resistance: Made from stainless steel grades (304/316L), it withstands harsh environments up to 600°C and resists chemical attack.
- Excellent Permeability: The porous structure provides low pressure drop while maintaining high flow rates, improving system efficiency.
- Easy to Clean & Regenerate: The sintered metal plate can be backwashed or ultrasonically cleaned, extending service life and reducing downtime.
- Customizable Dimensions: Available in various thicknesses, shapes, and sizes to fit specific equipment requirements.
Technical Parameters (Typical Values):
| Parameter | Value |
|---|---|
| Material | SS304 / SS316L (optional) |
| Number of Layers | 5 |
| Pore Size | 150 μm (nominal) |
| Thickness | 1.0 – 5.0 mm (customizable) |
| Porosity | 30% – 40% |
| Operating Temperature | Up to 600°C (in oxidizing atmosphere) |
| Max Pressure | Up to 20 bar (depending on design) |
Benefits for Your Application:
- Enhanced Gas Diffusion: The uniform pore structure ensures even gas distribution, critical for fuel cells, electrolyzers, and chemical reactors.
- Reduced Maintenance: High mechanical strength and corrosion resistance minimize replacement frequency, lowering total cost of ownership.
- Improved Process Efficiency: Low pressure drop and high permeability contribute to energy savings and higher throughput.
- Versatile Integration: The plate form factor allows easy installation into existing equipment or custom designs.
Trust & Quality Assurance:
With over 20 years of manufacturing experience and an annual export value of US$5 million – US$10 million, Anping County Boli Hardware Wiremesh Products Factory delivers consistent quality to global markets. Our products are shipped from major Chinese ports (Tianjin, Qingdao, Shanghai, Foshan) and serve clients across North America, South America, Europe, Asia, Africa, and Oceania. We are committed to providing customizable solutions that meet your exact specifications. Contact us today for a quote or technical consultation – let our expertise support your success.
Frequently Asked Questions (FAQ):
-
What materials are available for the sintered wire mesh plate?
Standard materials are stainless steel 304 and 316L. Other alloys (e.g., Hastelloy, Inconel) are available upon request. -
Can the plate be cut to custom sizes?
Yes, we offer custom cutting, shaping, and drilling to fit your equipment. Please provide your dimensional requirements. -
What is the maximum operating temperature?
For standard stainless steel, up to 600°C in air. Higher temperatures are possible with specialized alloys. -
How do I clean the sintered plate?
Backwashing with compressed air or liquid, ultrasonic cleaning, or chemical cleaning are effective methods. Avoid aggressive brushing that may damage the surface. -
Is the product suitable for high-pressure applications?
Yes, the 5-layer composite structure provides high strength. The maximum pressure depends on thickness and support design; consult our engineers for specific conditions. -
What is the typical pressure drop across the plate?
Pressure drop varies with flow rate and fluid properties. For air at 150 micron, typical ΔP is 10–50 mbar at 1 m/s face velocity. We can provide detailed data. -
Do you provide samples for testing?
Yes, sample plates are available for evaluation. Please contact us with your application details. -
What is the lead time for custom orders?
Standard lead time is 15–25 working days after confirmation, depending on quantity and complexity.
