PLC Control Automatic Process Cheese Cooker
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Good Price Cheese Spread Production Machine Cheese Cooker
-
Auto Lifting High Shear Mixer Emulsifying Cooker for Cheese
-
Factory Made 5000l Milk Pasteurizer Supplier
-
Factory Made 6000 Liter Milk Cooling Tanks Prices
-
Factory Made Milk Chilling Vat Manufacturer in Nepal Supplier
-
Customized 500l Milk Cooling Tank for Sale
Product Description
Product Description
The machine can be produced smear cheese or any pastry fillings. Put the raw materials or cheese block into pot then they are cooked by steam and cut, stired by high speed knife. The final product is formed as a paste when it is hot.
It consists of:
A pressure resistance pot with steam jacket;
Steam can direct jet into pot to heating and cooking the product in pot;
Vacuum pump and vacuum control system for sucking out moisture from product in pot; Automatic lifting and dumping funnel put in raw material device by hydraulic driver.
Pot dumped device by motor and gear box with brake block device, it is for put out the final product from pot ;
High speed and strong power knife, for cutting and stirring the raw material into fine grain, a paste form and uniformly mixed.
Low speed slicker on the top of cover driven by motor with gear box. Sealing cover and its lock device, they are driven by pneumatic device. Temperature control system to control the temperature in pot;
PLC and touch screen control system to order the machine running in program and set different programs for different products.
Specification
Knife motor | 18.5 kW |
Scraper motor | 0.75 kW |
Dumping motor | 0.55 kW |
Vaccum pump | 2.2 kW |
Steam consumption | 90 kg/batch |
Material Capacity | 90 kg/batch |
Machine Details
Low speed scraper
Made by PTFE, high temperature resistence.Make the mateiral not stick with the pot
High speed main knife
Big poower main knife, crushing and mixing the mateiral.
Vacuum system, and with steam injet inside of the pot directly
Uninterruptible Power Supply, protect the machine if power suddenly stop
