CE Standard Food Mesh Belt Drying Machine for Dehydrated Vegetable

CE Standard Food Mesh Belt Drying Machine for Dehydrated Vegetable photo-1
CE Standard Food Mesh Belt Drying Machine for Dehydrated Vegetable photo-2
CE Standard Food Mesh Belt Drying Machine for Dehydrated Vegetable photo-3
CE Standard Food Mesh Belt Drying Machine for Dehydrated Vegetable photo-4
CE Standard Food Mesh Belt Drying Machine for Dehydrated Vegetable photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2013
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

CE Standard Food Mesh Belt Drying Machine/Net Belt Dryer



Brief Introduction:

This type belt dryer is widely used in food industry,agriculture products and by-products, dehydrated vegetable,dried fruit,Chinese herbal medicine,fish products,feed and chemical industry and are suitable for drying of flaked,striped,cube and granule materials.For food industry,it is applicable to different vegetable and fruit such as root,halm,leaf,tuberos rot,bi granule and it works continuously and produce in batch.And at thee meantime,it can maintain content of nutition,color,etc of vegetable and fruit in most extent. The typical raw materials are garlic,cushaw,giantarum,turnip,yam,bamboo,shoot,capsicum,onion,apple,etc.



Feature:

1. Automatic and efficient,low energy consumption.

2. The drying area,air pressure,air amount,dry temperature and speed of net belt are adjustable in order to suit different characteristics of vegetable and fruit,and the requirement of quality.

3. It can adopts different process and equip necessary auxiliary equipment in accordance with different characteristics of fruit and vegetable.



Main Technical Parameter:

Model

DW-1.2-8

DW-1.2-10

DW-1.6-8

DW-1.6-10

DW-2-8

DW-2-10

Unit No.

4

5

4

5

4

5

Belt Width (m)

1.2

1.2

1.6

1.6

2

2

Length of drying section(m)

8

10

8

10

8

10

Thickness of the material to be covered(mm)

10-80

Temperature (℃)

60-130

Steam pressure (Mpa)

0.2-0.8

Steam consumption(kg/h)

120-300

150-375

150-375

170-740

180-500

225-600

Drying time(h)

0.2-1.2

0.25-1.5

0.2-1.2

0.25-1.5

0.2-1.2

0.25-1.5

Drying density(kg H2O/H)

60-160

80-220

75-220

95-250

100-260

120-300

Total power of the blower (kw)

9.9

12.1

9.9

12.1

18.2

22.2

Total power of the equipment (kw)

11.4

13.6

11.4

13.6

19.7

23.7

CE Standard Food Mesh Belt Drying Machine for Dehydrated vegetableCE Standard Food Mesh Belt Drying Machine for Dehydrated vegetableCE Standard Food Mesh Belt Drying Machine for Dehydrated vegetableCE Standard Food Mesh Belt Drying Machine for Dehydrated vegetableCE Standard Food Mesh Belt Drying Machine for Dehydrated vegetableCE Standard Food Mesh Belt Drying Machine for Dehydrated vegetable



Other Details:



1.Package: wooden cases for sea transportation

2.Delivery time: 30 working days after receiving the deposit

3.Installation : engineers available for installation and training overseas

4.Guarantee : 12 months after it is sent out



Plz feel free to contact me for any further information.
