Factory Genyond Shanghai Plate Type Pasteurization Machine Pasteurizer UHT Sterilizer Sterilization Equipment for Milk Juice
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2013
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Milk Processing PlantNegotiableMOQ: 1 -
Cow Farm Bulk Milk Cooling Tank (1000L)NegotiableMOQ: 1
-
GYC Mini Small Pasteurized Soy Milk Fruit Apple Juice PasteurizerNegotiableMOQ: 1
-
High Quality Cheese Mixer Cheese Emulsification MixerNegotiableMOQ: 1
-
Soy Milk / Camel Milk /Milk Pasteurization Machine for SaleNegotiableMOQ: 1
Product Description
PLATE TYPE PASTEURIZER
Milk plate pasteurizer and tube pasteurizer is a kind of sterilization equipment specially designed for milk drinks or similar
liquid materials. It's a ideal equipment to extend the shelf life of materials by sterilization and cooling. The heating, sterilization, heat preservation and cooling requirements designed according to different processes,
different materials and different process combinations can meet the process requirements. With a variety of safety protection measures, high temperature, alarm and low temperature backflow. At the same time, according to the requirements of users, automatic control system can be configured.
liquid materials. It's a ideal equipment to extend the shelf life of materials by sterilization and cooling. The heating, sterilization, heat preservation and cooling requirements designed according to different processes,
different materials and different process combinations can meet the process requirements. With a variety of safety protection measures, high temperature, alarm and low temperature backflow. At the same time, according to the requirements of users, automatic control system can be configured.
The pasteurzation temperature and pasteurization time is customized.
Device Description (For reference)
Technical parameters: 5ºC→65ºC (homogeneous)→85~95ºC (15S)→5ºC The unit can be connected to separator, homogenizer, flasher, degasser, etc.
This machine is used as a pasteurizer (widely used in fresh milk, milk beverages, fruit juice, tea, wine, ice cream, etc.), and it can also pre-sterilize materials when producing pasteurized milk (longevity milk). The machine has the characteristics of high heat recovery rate, low energy cost, rigorous structural design, convenient operation and simple maintenance.
Our strengths:
*It can be designed according to the special requirements of users
*Multiple products can be produced on the same production line
*It can produce high quality products and keep nutrients
*Aromatic substances can be added and mixed precisely
*Extend the shelf life of products
*Large output and small loss
*Application of high technology to save energy consumption
*According to the customer's choice, we can provide a variety of milk configuration
*Fruit juice type, packaging type and automation degree can be matched at will according to customer requirements.
Device Description (For reference)
Technical parameters: 5ºC→65ºC (homogeneous)→85~95ºC (15S)→5ºC The unit can be connected to separator, homogenizer, flasher, degasser, etc.
This machine is used as a pasteurizer (widely used in fresh milk, milk beverages, fruit juice, tea, wine, ice cream, etc.), and it can also pre-sterilize materials when producing pasteurized milk (longevity milk). The machine has the characteristics of high heat recovery rate, low energy cost, rigorous structural design, convenient operation and simple maintenance.
Our strengths:
*It can be designed according to the special requirements of users
*Multiple products can be produced on the same production line
*It can produce high quality products and keep nutrients
*Aromatic substances can be added and mixed precisely
*Extend the shelf life of products
*Large output and small loss
*Application of high technology to save energy consumption
*According to the customer's choice, we can provide a variety of milk configuration
*Fruit juice type, packaging type and automation degree can be matched at will according to customer requirements.
Processing flow for reference; It is customized.
Model |
Process capacity |
Heat exchanging area(㎡) |
power(kw) |
Steam consumption(kg/h) |
External dimension(mm) |
weight (kg) |
GBR-3-0.5 |
0.5t/h |
5 |
5.2 |
52 |
1200×1200×1500 |
790 |
GBR-3-1 |
1t/h |
8 |
5.2 |
60 |
1500×1500×1800 |
880 |
GBR-3-2 |
2t/h |
13 |
6 |
104 |
1800×2000×1800 |
980 |
GBR-3-3 |
3t/h |
20 |
6 |
156 |
2000×2000×2000 |
1080 |
GBR-3-4-5 |
4-5t/h |
30-45 |
8 |
260 |
2250×2000×2200 |
1250 |
GBR-3-6-8 |
6-8t/h |
35-50 |
8 |
400 |
2250×2000×2200 |
1250 |
GBR-3-10 |
10t/h |
60 |
11 |
520 |
2800×2000×2200 |
1650 |
GBR-3-15 |
15t/h |
75 |
15 |
780 |
3000×2200×2200 |
2150 |
GBR-3-20 |
20t/h |
80 |
18 |
945 |
3300×2200×2200 |
2350 |
TUBE UHT STERILIZER
Technicals: (for reference)
5℃→65℃(homogenizer)→137℃(3-5S)→20℃-25℃. This UHT system adopts ultra high heat treatment to sterilize the liquid dairy products, tea drink and juice for the the aseptic filling production; the sterilize temperature is 137℃ holding for 3~5S,by this procedure to remain the nature nutrition and flavor of the milk and juice;
This machine has the following characteristics: high heat reuse efficiency, tight structure design fine looking and temperature control well etc; discharge temperature of this machine can be self controlled so it is available for the hot filling procedure and meanwhile for aseptic cold filling; The sterilization temperature and holding time is customized.
5℃→65℃(homogenizer)→137℃(3-5S)→20℃-25℃. This UHT system adopts ultra high heat treatment to sterilize the liquid dairy products, tea drink and juice for the the aseptic filling production; the sterilize temperature is 137℃ holding for 3~5S,by this procedure to remain the nature nutrition and flavor of the milk and juice;
This machine has the following characteristics: high heat reuse efficiency, tight structure design fine looking and temperature control well etc; discharge temperature of this machine can be self controlled so it is available for the hot filling procedure and meanwhile for aseptic cold filling; The sterilization temperature and holding time is customized.
