ChinaHome > Products > ADL Series Prepayment Meter > Acrel single phase prepayment meter ADL100-EYRF support cost control time control radio frequency card recharge
Acrel single phase prepayment meter ADL100-EYRF support cost control time control radio frequency card recharge
USD $52.5 - $52.5
/ Piece
1 Piece(Min.Order)
- 100 Piece / Pieces per Month
- T/T
You May Like
-
Acrel ADL100-EYZ single phase prepayment meter support radio frequency card and prepayment online 1*RS485
-
Acrel ADL100-EYNK complete electrical meter single phase support prepayment online built-in magnet help relay to realize on-off
-
Acrel three phase prepayment meter ADL300-EYRF 1*RS485 realize load power off with circuit breaker support cost control
-
Acrel ADL300-EYNK complete electrical parameter measurement three phase support prepayment online 1*RS485
-
Acrel ADL300-EYZ three phase prepayment meter 1*RS485 support radio frequency card and prepayment online
-
Acrel ADL300-EYNK/WF 4G WiFi frequency band complete electrical parameter measurement three phase support prepayment online 1*RS485
Product Description
Technical Parameter | ADL100-EY | ADL300-EY | |
Voltage | Nominal Voltage | 220V | 3*220V/380V |
Nominal Frequency | 50/60Hz | ||
Consumption | <4VA (Each Phase) | ||
Current | Maximum Current | 60A | 6A, 80A |
Consumption | Connect Directly: 0.04A, Connect via CT: 0.002A | ||
Measurement Performance | Accuracy | Class 1 | Class 0.5S |
Clock | Accuracy | Error ≤ 0.5s/d | |
Active Pulse | Width | 80ms ± 20ms | |
Constant | 1600imp/kWh | 6400imp/kWh, 400imp/kWh | |
Outline | L*W*H (mm) | 72*88*70 | 144*88*70 |
Communication | Interface | RS485 | |
Protocol | Modbus-RTU | ||
Temperature | Working | -25℃-55℃ | |
Storage | -40℃-70℃ | ||
Relative Humidity | ≤95% (No Condensation) | ||
Altitude | ≤20000m | ||
