Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15

Tianjin Jianfeng Hydraulic Machinery Co., LTD
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 thumbnail-1
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 thumbnail-2
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 thumbnail-3
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 thumbnail-4
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 thumbnail-5
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 photo-1
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 photo-2
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 photo-3
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 photo-4
Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15 photo-5
US$ 35000 - 100000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Jianfeng
Place of Origin:
China
Model Number:
JF-QT10-15
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Jianfeng
Place of Origin China
Model Number JF-QT10-15
Certification ISO9001:2005
Type Interlock Block Making Machine
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12 month
Dimension(L*W*H) 4300*1800*2500
Voltage 380V
Power 85 KW
Condition New
Automatic Yes
Capacity 64800 pcs for holland bricks per day
Method Hydraulic Pressure
Processing Brick Molding Machine
Brick Raw Material Crushed Stone

Middle Type Fully-automatic Multi-functional Interlock Brick Machine JF-QT10-15


1、Changing any molds can make different kinds of bricks and blocks.

2、Back and forth way of feeding forks guarantee feeding raw materials efficient and uniform.

3、Vibration combined with hydraulic pressure to ensure uniform density.

4、Forced mold synchronization, ensure consistent thickness, smooth demold, high yield.

5、Automatic operation for pallet sending,brick receiving,,vibrating and pressing.


NO.

Main Technical Parameter

1

Actuating shock force

98KN

7

Installed capacity

44KW

2

Frequency of shock

6500(Time/Minute)

8

Weight of brick machine

12T

3

Amplitude

15mm

9

Maximum pressure

10T

4

Noise

95db(A)

10

Pallet size

1100×900× 25(mm)

5

Shock time

8(Second/Time)

11

Operation number

6 persons

6

Overall dimension

7265×2900×4100(mm)

12

Area size

≥5000 m2



Brick Type & Production

Product specification (L ×W× H)mm

Brick picture

Pieces per Mould

Production per hours

Produce period

Standard brick 240* 115*53mm



48 Pieces

8640 Pieces

20Second/Time

Hollow brick 190*190*390mm



10 Pieces

1800Pieces

20Second/Time

Interlocking brick 225*112.5*60mm



24 Pieces

4320 Pieces

20Second/Time

Holland brick 200* 100*60mm



36 Pieces

6480 Pieces

20Second/Time

Multi-hole brick 240* 115*90mm


24 Pieces

4320 Pieces

20Second/Time

Border stone 1000* 150*300mm



2 Pieces

180 Pieces

40Second/Time


Product Tags: brick making machinery , hollow block machine , solid brick machine , wall block machine , interlock brick machinery , pavement brick machine , curbstone brick machine , brick production line , floor tile brick machine
