Product Application
WT2-10 interlocking brick machine line can produce soil blocks and soil pavers with high capacity(5200pcs/8hours).it is a production line includes soil crusher,screen,mixer,converyor and host machine.Two types:hydraulic and diesel engine.
Main Features
1) High capacity,2pcs/mold,5200pcs/day.
2) hydraulic press,with good density of blocks
3) automatic production line ,save labor cost.
4)material :soil (95%)cement (5-10%)
Machine Parts
Name:soil crusher
Brand: wante
Overall size:1100(L)×1100(W)×1400(H)mm
Motor:5.5KW
Capacity:500KGS/H
Electricity:380V/220V/ (adjustable)
Total weight:300 KGS
Machine Parts
Name: Soil screen
Brand:wante
Power:3KW
Rated power:380V or 220V
Size:Diameter:500mm
Total weight:320KGS
Machine Parts
Name: JD350 mixer
Brand: wante
Overall size:1200(L)×1200(W)×1300(H)mm
Shaping cycle:5 mins
Volume:350L (25Kgs Cement)
Electricity:380V/220V/ (adjustable)
Total weight:330KGS
Main Features
Name: converyor belt
Brand: wante
Belt width (M):6m.4.5m
Belt length (M)/KW:6/2.2
Belt speed (M/S):2
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
