Overview
LA-SWM3-DC10G0416C08 is a next-generation aggregation 10GE switch. It is targeted at the IP MAN (metropolitan area network), government and enterprise networks, Internet café and disk-less working environment. It is developed based on high-performance hardware and a software platform with our own independent intellectual property rights. It supports functions such as powerful ACL, flexible QinQ, 1:1 or N:1 VLAN switching, Ethernet OAM, carrier-level QoS and industry-level 10GE Ether-ring, ensuring this switch series meets application requirements in all kinds of complicated sites. It also supports layer-3 routing protocol.
Specifications
PART NO |
LA-SWM3-DC10G0416C08 |
Interface |
16×100/1000M SFP, 8×GE SFP/TX combo, 4×10 GE/GE SFP+ |
Console |
1 RJ45 |
Backplane |
128 Gbps |
Forwarding rate |
96 Mpps |
Total output BTU (1000BTU/H=293W) |
153.58 |
Fan number |
2 |
Noise@25°C(dBA) |
45 |
MTBF(H) |
>50,000 |
Forwarding mode |
Store-forward |
Flash (MB) |
32 |
DRAM (MB) |
256 |
MAC |
16K |
Buffer size (MB) |
1.5 |
Interface Vlan |
64 |
Routing table |
2040 |
Jumbo frame |
9K |
Power supply |
AC:100V-240V,50-60Hz; 45W |
Power consumption | |
No-load |
|
Full load |
|
Chassis | |
Dimensions (W x D x H) (mm) |
440*280*44 |
Weight (KG)(empty) |
4 |
Package | |
Dimensions (W x D x H) (mm) |
570*448*94 |
Weight (KG) |
5.2 |
Ordering Information | |
LA-SWM3-DC10G0416C08 |
Ethernet Layer-3 lite switch with 24 GE and 4 10GE ports (1 Console port, 16 100M/1000M SFP ports, 8 GE SFP/TX combo ports, 4 10GE/GE SFP+ ports; AC 220V power supply, the cooling fan, 1U, standard 19 inch rack-mounted installation) |
