6206-2.8v
250mA low voltage differential linear regulator
Overview:
The XC6206 series is a high-precision, low-power model,
High voltage, positive voltage regulator chip with CMOS
Process and laser fine tuning technology. At the output current,
The input and output voltage difference is also very small. The XC6206 series chips include
A current limiting circuit, a driver transistor, and a
A high-precision reference voltage source and an error correction circuit.
The XC6206 series can use low ESR ceramic capacitors. This current limit
The return circuit of the controller can be provided for the current limiter and output pins
Provide short-circuit protection. By using laser fine tuning technology, the chip's
The range of output voltage is 1.2V to 5.0V, with an interval of 0.1V
Application:
High precision output voltage: ± 2%
Output voltage: 1.2V~5.0V (in steps of 0.1V)
Maximum working voltage: 6V
Extremely low static bias current (Typ.=8.0 μ A)
Strong carrying capacity: when Vin=4.3V and Vout=3.3V
Iout=300mA
Extremely low input and output voltage difference:
0.2V at 90mA and 0.40V at 200mA
Good input stability
● Low temperature adjustment coefficient
Can be used as a regulator and reference voltage
application
● Battery powered system
● Cordless telephone equipment
● Wireless control system
● Portable/handheld computer
● Portable consumer devices
● Portable instruments
● Electronic equipment
● Automotive electronic equipment
● Voltage reference source
