Standard configuration :
KND1000 control system
Lubricating system
Manual chip conveyor
Optional configuration :
Control system :KND,GSK,Siemens etc.
Chain type automatic chip conveyor
The forth axis
Spindle center water outlet ,spindle oil coolant
The main performance characteristics：
1.The fuselage and main components are high strength cast iron, microstructure stability, ensure the stability of machine tool for long-term use.
2.The column at the bottom of A type bridge type structure, combined with the big box base, greatly reduce the vibration of machine on heavy cutting
3.The pre tension precision ball screw drive
4.The high speed, high precision, high rigidity spindle unit
5.The design of oil-water separation
6.The intermittent automatic lubrication
7.Automatic scraping knife system
Application：
The vertical machining center can be applied to many fields such as mechanical processing and mould manufacturing, can adapt from roughing to finishing processing requirements, has the characteristics of high precision, high efficiency
Product main technical specifications:
specifications |
unit |
VMC650 |
Table size |
mm |
800x400 |
X axis travel |
mm |
650 |
Y axis travel |
mm |
400 |
Z axis travel |
mm |
500 |
|
Distance between spindle center and column surface |
mm |
469 |
|
Distance between spindle nose and table surface |
mm |
100-600 |
T slot |
3-18*125 |
|
Spindle taper |
mm |
BT40 |
Max. spindle speed |
r/min |
8000(10000 optional) |
Main motor power |
kw |
5.5 |
X/Y/Z axis servo motor torque |
N.M |
10/10/15 |
X/Y/Z motor connection |
direct |
|
X/Y/Z guide rail form |
3 axis linear guide rail |
|
Max.table load |
kg |
550 |
Automatic tools changer |
16 Armless type(optional:24 arm type) |
|
Max.tool weight |
kg |
7 |
Max. tool length |
mm |
250/350 |
Max. tool diameter |
mm |
100(Adjacent)/150(Apart) |
X/Y/Z axis rapid traverse |
M/min |
24(optional :48) |
Cutting feed speed |
M/min |
10 |
Position accuracy |
mm |
±0.005 |
Repeat positioning accuracy |
mm |
±0.003 |
Machine dimension |
mm |
2400x2000x2550 |
Machine weight |
kg |
4000 |
