1.Description:
Used to press metal scraps , which thickness are less than 6~10mm under normal conditions, including scraps metal materials, scrap steel, waste oil tank and disintegrated vehicle shell, etc. into blocks. It has semi-automatic and automatic function.
2.Technical parameters:
Model |
Normal force (KN) |
Material box size (mm) (LxWxH) |
Bale size (mm) (WxH) |
Bale weight (Kg) |
Production Ton/hour |
Power (Kw) |
Type of baler out |
Operation |
YD-4000A |
4000 |
2500x1600x1200 |
600x600 |
500~700 |
6~8 |
45 |
Push-out |
Auto PLC |
YD-4000B |
4000 |
2800x1800x1200 |
650x650 |
800~1000 |
8~10 |
45*2 |
Push-out |
Auto PLC |
YD-6000 |
6000 |
3000x2000x1400 |
650x650 |
1000~1500 |
10~15 |
45*3 |
Push-out |
Auto PLC |
3. Features:
a. Big material box design that improves operation efficiency greatly
b.It applies automatic PLC control that is safe, reliable and reduces labor intensity
c.Each hydraulic oil cylinder applies quick-action technology that improves operation efficiency greatly and reduces energy consumption.
* Electric parts and hydraulic system
a.PLC system with remote control system, and buttons control cabinet.
b.The hydraulic system has the high and the low pressure system, and adds the damp control to reduce the shock of each action.
c.When the oil cylinder working, forward will be high pressure, and back will be low pressure. When main cylinder and side cylinder retract to the place, there is a monitor signal examination.
d.Cooling system will use separated control system, add 3Kw motor and yb1-32 lamina pump and electric cabinet, add the oil filter at the inlet and pressure meter.When press the Emergency stop button, turn off all the control power supply.
4.Certifications:
Package Type:
hydraulic metal compression baler packing: plastic wrapping and wood case, steel wire fixed in the container
