It is used for chemical, chemical high-pressure synthesis or catalytic reaction, need to simultaneously determine the temperature, determine the rotational speed and add inert gases, calibration pressure and online sampling requirements of the experimental environment.
Technical Highlights:
1. Observe the whole reaction process.
2. The observation window is made of JGS2 high transmittance quartz glass, which can realise on-line photochemical reaction under high pressure.
Application Examples:
It is suitable for photochemical high-pressure reaction, carbon dioxide CO2 reduction, carbon dioxide CO2 reduction to methanol.
CO2 reduction to methane CH4, NOx reduction and degradation, high pressure photocatalytic degradation of formaldehyde.
NOx reduction and degradation, high-pressure photocatalytic degradation of formaldehyde, etc. Photocatalytic reaction, Fischer-Tropsch reaction, hydrogenation reaction, polymerisation reaction, homogeneous reaction and CO2 supercritical reaction, etc.
Product Parameters:
| Kettle Body,Valve and connection material | UL316L |
Working pressure | ≤12.5MPa |
Reactor chamber | Fully encapsulated in PTFE |
Temperature Range | 0-300ºC |
Rotary speed | 0-1500 rmp |
Pipe outer diameter | 3mm |
Wall thickness | 1mm |
Stirring power | 100W |
Toom temperature | 280 °C |
Temperature control accurac | <±0.5 °C |
