Product Description
The machine adopts originally fiber laser source and speedy Gavol scanning system. High quality of light beam, long using time, stable equipment performance exempts maintenance. It is speedy, and precious. Marking has non-touched process, permanent effect, humanized operation, and stable running. The proprietary control software may compatible software output of AutoCAD, CorelDraw, Photoshop, etc. It can realized automatic edition and correction of characters, signs, graphs, images, bar codes, two-dimensional codes, automatically increased serial numbers. It can support various file formats like PLT, PCX, DXP, BMP, JPG, and so on. It may use TIF fonts directly. 24-hour non-stop running makes it meet the demand of massive on-line and off-line industrialized production.
Technical Parameters
Model |
TXT-DB-F20/30/50/100 |
Laser wavelength |
1064nm |
Laser power |
20W/30W/50W/100W |
Controller/software |
Beijing JCZ EZCAD software |
Modulation frequency |
20 ~ 30 KHz |
Height clearance |
200mm |
Max. Marking speed |
7000 mm/s(according to the material) |
Marking area |
300*300mm |
Repeatability |
±0.001 mm |
Marking depth |
0.01 ~ 0.5mm(according to the material) |
Laser module life |
Longer than 100,000 hours |
Beam Diameter |
10um |
Gross power |
500w |
Cooling |
Air cooled |
Power supply |
Single phase 220V AC 50/60Hz |
Dimension |
800*600*560mm |
Weight |
70kg |
Warranty service |
2 years |
File formats |
Vectors PLT, DXF,AI,CAD,CDR, Bitmaps JPG,BMP,PNG |
Accessories |
Rotary table compatible with marking |
Application
The machine is widely applied in electronic component, the communication, the spare parts of automobiles and motorcycles, instrument and meter, aerospace, war products, hardware and machinery, measuring and cutting tools, sanitary equipment, medication, food and beverage, cosmetics, drugs packing, medical appliance, solar energy, handicraft and so on. It is suitable to mark on all kinds of metal and partial nonmetallic material.
