NI PXI-2530B Relay Switch Module

Product Introduction

NI PXI-2530B is a relay switch module produced by NI (National Instruments). It is a switch module used for the PXI (PCI eXtensions for Instrumentation) platform, used to switch and connect signals in testing and measurement applications. Here are some product details for this module:

Number of channels: The NI PXI-2530B module has 32 independent relay channels, which can simultaneously control multiple signal sources or connect multiple target devices.

High voltage and high current: The module can withstand high voltage and high current signals to meet various application requirements.

Low insertion loss: The module has low insertion loss characteristics, ensuring minimal interference and distortion in signal transmission.

Fast switching speed: The module supports fast switching speed and can achieve signal path switching and connection within milliseconds.

High reliability design: Adopting reliable relay and switch technology, with long lifespan and high stability, suitable for long-term operation and repeated testing.

Multiple switch types: The module provides multiple relay switch types, such as single pole single throw (SPST), double pole single throw (DPST), single pole double throw (SPDT), etc., to meet the needs of different applications.

Driver software support: The NI PXI-2530B relay switch module is equipped with driver software suitable for various programming environments, such as LabVIEW and NI-DAQmx, making it convenient for users to quickly develop and integrate.

PXI bus interface: The module adopts a standard PXI bus interface and seamlessly integrates with other PXI modules and devices, facilitating system expansion and interconnection.

Product image display
