Product Introduction
NI PXI-2558 is a relay module produced by NI (National Instruments) company, mainly used for switching and routing different signal paths. The following are some of the main functions and features of this module:
Multi channel relay: With 8 independent relay channels, it can achieve multi-channel signal switching and routing operations.
High speed switch: Supports switch speeds up to 10 MHz, suitable for high-speed signal switching and transmission applications.
Low resistance and low insertion loss: The relay channel has low resistance characteristics and low insertion loss, ensuring minimal interference and distortion in signal transmission.
High voltage and high current: Supports up to 200 V voltage and 2 A current, suitable for various voltage and current levels of applications.
Programmable control: Through software programming and commands, relay channels can be flexibly controlled and operated to achieve automation and remote control.
Protection function: Built in overcurrent and over temperature protection functions can ensure the safe operation of the equipment and provide reliable signal switches and protection.
PXI bus interface: Adopting a standard PXI bus interface, it seamlessly integrates with other PXI modules and devices, facilitating system expansion and interconnection.
Driver software support: The NI PXI-2558 relay module is equipped with driver software suitable for various programming environments, such as LabVIEW and NI-DAQmx, making it convenient for users to quickly develop and integrate.
Product image display
