Product Introduction
NI PXIe-5630 is a network analysis module used for high-frequency and radio frequency (RF) signal analysis. The following are some product details about the NI PXIe-5630 network analysis module:
High frequency range: NI PXIe-5630 supports signal analysis in the high frequency range, covering the frequency range from 10 MHz to 26.5 GHz. It is suitable for signal analysis and measurement in the fields of radio frequency and microwave.
High precision measurement: This module has high-precision measurement capabilities and can provide accurate measurement of RF parameters and network parameters. It supports S parameter measurement, including scattering parameters (S11, S21, S12, S22) and transmission parameters (S21, S12), and can be used for precise signal analysis and network analysis.
Dynamic range: NI PXIe-5630 has a wide dynamic range and can measure and analyze various signal strength levels. It provides highly sensitive measurements that can detect and analyze weak signals, while also processing measurements of high-power signals.
Flexible measurement mode: This module supports multiple measurement modes, including single ended mode and differential mode. Users can choose appropriate measurement modes and connection methods according to their needs.
Fast measurement speed: NI PXIe-5630 has fast measurement speed, enabling efficient signal analysis and measurement. It has fast sampling rate and data processing capabilities, and can quickly obtain and analyze signal parameters.
Software support: This module is tightly integrated with NI's software tools, providing rich functionality and easy-to-use programming interfaces. Users can use LabVIEW, LabWindows/CVI and other software for signal analysis and data processing to achieve flexible application development and Test automation.
Product image display
