Product Introduction
NI PXI-2534 is an interface module that provides a wide range of interface functions for communication with various vehicle networks and communication buses. The following are the main functions of the NI PXI-2534 interface module:
Multiple vehicle network support: NI PXI-2534 supports multiple vehicle networks and communication buses, including CAN (Controller Area Network), LIN (Local Interconnect Network), FlexRay, Ethernet, and more. It can communicate with various vehicle electronic systems and support corresponding communication protocols and standards.
Vehicle diagnosis and communication: This module provides vehicle diagnosis and communication functions, which can be used to read and write data from the vehicle electronic control unit (ECU). It supports diagnostic protocols such as ISO 15765-2 (CAN diagnostic protocol) and ISO 15031-5 (diagnostic extension protocol) for vehicle fault diagnosis and data communication.
Data capture and analysis: NI PXI-2534 has data capture and analysis functions, which can capture data streams on the vehicle network and perform real-time analysis. It supports data filtering, triggering, and storage, and can capture and analyze key data in the vehicle network for troubleshooting and performance optimization.
Flexible configuration and control: This module has flexible configuration and control options, allowing users to configure interfaces and protocols as needed. It provides easy-to-use software interface and programming interface for interface setting, data control and Test automation.
Software support: NI PXI-2534 is tightly integrated with NI's software tools, providing rich functionality and easy-to-use programming interfaces. Users can use software such as LabVIEW to develop and test vehicle network communication, and realize flexible application development and Test automation
Product image display
