Product Introduction
The NI PXI-5105 oscilloscope module is a high-performance data acquisition and signal analysis device with the following main functions:
High bandwidth and high sampling rate: The NI PXI-5105 oscilloscope module provides high bandwidth and high sampling rate, which can accurately capture high-frequency signals and rapidly changing waveforms. It can meet the measurement and analysis needs of high-speed signals.
Multi channel data acquisition: This module has multiple input channels and can simultaneously collect multiple signals. The multi-channel design makes it suitable for applications that require simultaneous acquisition of multiple signals, such as multi-channel data recording and signal analysis.
High precision and low noise: The NI PXI-5105 oscilloscope module has high-precision data acquisition and low noise characteristics, which can provide accurate and clear waveform measurement results. It adopts high-performance analog-to-digital converters and signal processing technology, which can achieve high-precision signal measurement.
Multiple trigger modes: This module supports multiple trigger modes, including edge trigger, pulse trigger, window trigger, etc. Users can set appropriate triggering conditions as needed to capture waveform events of interest.
Flexible data storage and export: The NI PXI-5105 oscilloscope module provides flexible data storage and export functions. It can save the collected data to internal memory or external storage media, such as hard disk or Solid-state drive. In addition, users can also export data to common file formats such as CSV, MATLAB, etc., to facilitate subsequent data analysis and processing.
Software support: This module is tightly integrated with NI's software tools, providing rich functionality and easy-to-use programming interfaces. Users can use LabVIEW, NI-DAQmx and other software for module configuration, data acquisition and signal analysis to achieve Test automation and data processing.
Product image display
