DUAL OUTPUT MAX 7.2KW 8.2KW 10.2KW SOLAR INVERTER WITH TOUCHABLE LCD
US$ 1 - 1000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Quance Solar Inverter
Place of Origin:
China
Model Number:
Max Solar Inverter
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
7 days
Related Products
-
Lithium Iron Battery 51.2V LiFe PO4 Wall MountedUS$ 1 - 100MOQ: 1 Piece -
NM II PLUS SERIES 3.5KW 24V 5.5KW 48V OFF GRID PV SOLAR INVERTER CHINA MANUFACTURE PURE SINE WAVEUS$ 1 - 100MOQ: 1 Piece
-
New Energy Vehicle Power Bank NEV Power Box Solar NEV Charger SupplyNegotiableMOQ: 1 Piece
-
Li-MAX Lithium Iron Battery Pack for Lead-Acid Battery Replacement Solar CellUS$ 1 - 100MOQ: 1 Piece
-
Non Oriented Silicon Steel 0.35mm for Solar Inverter Transformer Reactor Core Low LossUS$ 0.55 - 1.25MOQ: 100 Kilograms
Brand Name
Quance Solar Inverter
Place of Origin
China
Model Number
Max Solar Inverter
Application
Home
Specification
Normal
Output Voltage (V)
48V
Solar Power (W)
7200W 8200W 10200W
Load Power (W)
7200W 8200W 10200W
VICTOR MAX 7.2KW 8.2KW 10.2KW SOLAR INVERTER
Features：
1.Pure sine wave solar inverter(on/off Grid)
2.Output power factor 1.0
3.WIFI&GPRS available for IOS and Android ·
4. Inverter running without battery
5.One-key restoration to factory settings.
6. Built-in Lithium battery automatic activation
7.Built-in 160A MPPT solar charger
8.High PV input voltage range(90~450VDC)
9.Built-in anti-dusk kit for harsh environment
10.Smart battery charge design to optimize battery life ·
11.Dual output
12.Touch button
| MODEL | 7200W 48V | 8200W 48V | 10200W 48V |
| Maximum PV Input Power | 7200W | 8200W | 10200W |
| Rated Output Power | 7200W/7200VA | 8200W/8200VA | 10200W/10200VA |
| Maximum Solar Charging Current | 160A | 160A | 160A |
| GRID-TIE OPERATION | |||
| PV Input(DC) | |||
| Nominal DC Voltage / Maximum DC Voltage | 360VDC/500VDC | ||
| Start-up Voltage/Initial Feeding Voltage | 90VDC/120VDC | ||
| MPPT Voltage Rang | 90VDC~450VDC | ||
| Number of MPPT Trackers / Max Input Current | 1/27A | ||
| GRID OUTPUT(AC) | |||
| Nominal Output Voltage | 220/230/240VAC | ||
| Output Voltage Range | 195~253VAC | ||
| Nominal Output Current | 31.3A | 35.6A | 44.3A |
| Power Factor | >0.99 | ||
| Feed-in Grid Frequency Rang | 49~51±1Hz | ||
| EFFICIENCY | |||
| Maximum Conversion Efficiency(DC/AC) | 98% | ||
| TWO LOAD OUTPUT POWER | |||
| Full load | 7200W | 8200W | 10200W |
| Maximum Main Load | 7200W | 8200W | 10200W |
| Maximum Second Load(battery mode) | 2400W | 2733W | 3400W |
| Main Load Cut Off Voltage | 44VDC | 44VDC | 44VDC |
| Main Load Return Voltage | 54VDC | 54VDC | 54VDC |
| OFF-GRID OPERATION | |||
| AC INPUT | |||
| AC Start-up Voltage/Auto Restart Voltage | 120-140VAC/180VAC | ||
| Acceptable Input Voltage Range | 90-280VAC or 170-280VAC | ||
| Maximum AC Input Current | 40A | 40A | 50A |
| Nominal operating frequency | 50/60Hz | ||
| Surge power | 14400W | 16400W | 20400W |
| PV INPUT(DC) | |||
| Maximum DC Voltage | 500VDC | ||
| MPPT Voltage Range | 90VDC~450VDC | ||
| Number of MPPT Trackers/Maximum Input Current | 1/27A | ||
| BATTERY MODE OUTPUT(AC) | |||
| Nominal Output Voltage | 220/230/240VAC | ||
| Output Waveform | Pure sine wave | ||
| Efficiency (DC to AC) | 94% | ||
| BATTERY & CHARGER | |||
| Nominal DC Voltage | 48VDC | 48VDC | 48VDC |
| Maximum Solar Charging Current | 160A | 160A | 160A |
| Maximum Charging Current | 140A | 140A | 140A |
| GENERAL | |||
| PHYSICAL | |||
| Dimension,Dx W x H(mm) | 420*310*110 | ||
| Cartoon Dimension,DXWXH(mm) | 588*463*205 | ||
| Net Weight(kgs) | 13.1 | 14.2 | 14.5 |
| Gross Weight(kgs) | 14.1 | 15.7 | 16.0 |
| NTERFACE | |||
| Communication Port | RS232/WIFI/Remove LCD/GPRS | ||
| ENVIRONMENT | |||
| Operating Temperature | -10～50℃ | ||
