Main Features:
●Built in inverter and Smart BMS. Saveinstallation time andlabor.
●WIFI APP Management Optional.
●Longer Cycle Life6000 Cycle Life @80% DOD.
●Easy to move with wheels. Compact and portable design, indoor andoutdoor workable.
●Triple input Solar energy charging ; Utility Grid charging and Diesel Engine charging.
| Model | NEV power bank |
| Energy storage capacity | 5.12KWh |
| Rated power | 5.5KW (5-11KW Optional) |
| Phase | Single phase |
| Battery | |
| Voltage | 230Vac |
| Voltage range | 170-280Vac (for personal computer);90-280Vac(for home appliance) |
| Frequency | 50/60HZ(Auto detection) |
| PV INPUT | |
| Rated Voltage | 51.2V |
| Battery Capacity | 100AH |
| Continuous Discharge Current | 100A |
| Standard Charging Current | 20A |
| Fast Charge Current | 80A |
| Battery Type | LiFePO4 |
| Cycle Life | >6000 |
| Battery Voltage Range | 43.2~58.4V |
| AC/PV INPUT | |
| Grid Voltage Range | Appliances: 90-280Vac; UPS:170-280Vac50Hz/60Hz(Auto detection) |
| Rated Grid Frequency | 50Hz/60Hz(Auto detection) |
| PV maximum Input Power | 5500W |
| PV maximum open-circuit voltage | 500V |
| MPPT Voltage Range | 120~450V |
| Charging and discharging efficiency of the whole machine | 93% |
| AC/DC OUTPUT | |
| AC Output Voltage | 230V+5% |
| AC Output Power | 5500W |
| EV Charging Power | 4KW for AC charging pile |
| Overload Capacity | 5s@2150%load;10s@110%-150%load |
| DC Output | DC12V10A:TYPE-C 5V3.4A,9V2.5A12V/2A |
| Physicals | |
| Dimension(D*W*H)mm | 250*600*770 |
| Net Weight, kg | 65+2kg |
| Operating Temperature Range | Charging temperature: 0-45C; Discharging temperature: -20C-60C |
| Humidity | 5%~95% |
| Maximum working altitude | 4000m(Derating up 1500m) |
| Cool ing Method | forced air cooling |
| Dustproof /Waterproof | IP20 |
| Executive standards | CE,RCM,CEC,VDE2510-50,IEC62619,1EC60730,UN38.3 |
