GYM100S-3 Industrial Door Operator with Frequency Conversion Limit
PRODUCT FEATURES
1, German technology support, European standard production, world-class quality.
2, exquisite appearance design, highlighting the high-end brand image.
3, precision worm wheel drive, stable and reliable, ultra low noise.
4, oil immersed lubrication can effectively improve the service life of products.
5, the motor brake device, reduce motor inertia, effectively improve the accuracy of the limit.
6, the worm and worm gear precision limit adjustment device has high accuracy and convenient adjustment.
7, super strong thickening box can effectively improve product rigidity and enhance product stability.
8, the universal automatic chain guide mechanism, the product can adapt to more installation space needs.
9, multi-layer anti shedding surface spraying treatment makes the product more beautiful and durable.
PRODUCT PERFORMANCE PARAMETER
Types | GYM100S-3 | ||
Input Voltage | AC220V（Three-phase） | Noise | ≤55dB |
Rated Power | 650W | Manual Chain Form | 360. universal chain |
Start Torque | 100N.m | Rapid Outage Of Power Failure | Rope release (optional) |
No-Load Running Time | 15min | Maximum Limit Stroke | The output shaft turns to 20 turns. |
Maximum Lifting Area | 25㎡（4CMthick door plank） | Limit Switch Type | Precise adjustment device for mechanical worm wheel and worm |
Matching Electronic Control Form | Split type | Output Shaft Aperture | Φ25.4mm |
Thermal Protection Degree | 120℃ | Use Of The Environment | （-20℃ ～+45℃） |
Deceleration Mechanism | Deceleration mechanism of copper worm gear and worm gear | Working System | S2 20% |
No-Load Speed | 24r/min | Protection Grade | IP54 |
Lubrication Method | Oil immersion | Whole Machine Quality | 14KG |
