Brief introduction
iSecus DT-810 is a non-linear junction detector developed with modern advanced technology. It can detect any electronic equipment hidden in walls, floors, ceilings, lamps, furniture or containers. Whether these electronic devices are transmitting signals or not, they are alerted by display, vibration and sound prompts, so that the detectors can focus on hidden targets.
Technical Principles:
Nonlinear junction detector emits S-band fundamental wave to the target area or object, and the receiver captures the second and third harmonics generated by the target object. Artificial intelligence algorithm is used to analyze the harmonic law, so as to detect and identify the electronic equipment with non-linear junctions.
Application scenarios:
It can be widely used in government, public security, prison, justice, army, education examination, business security and personal privacy protection, etc.
Business Safety: Detecting unauthorized electronic devices, such as eavesdroppers, mobile phones and devices with SIM cards, hidden in company board rooms or secret offices;
Public Safety: Detecting electronic devices hidden or prohibited from use in safe areas, such as detonating devices, remote controllers, etc.
Personal Privacy Protection: Hidden cameras and surveillance devices such as recording pens, cameras, etc. in residential buildings and hotels.
Product highlights:
* High positioning accuracy: The product uses 2400MHz radio frequency detection technology with high precision positioning characteristics.
* High semiconductor recognition ability: the product built-in spectrum analyzer supporting second and third harmonic detection can quickly and effectively identify devices containing semiconductors.
* High Sensitivity: Especially for SIM card devices with high sensitivity, to ensure that secrets, mobile communications equipment can be quickly detected.
* Low false alarm rate: built-in nondestructive detection algorithm greatly improves the detection capability, and the false alarm rate is very low.
* High Safety and reliability: meets the requirements of electromagnetic radiation and absolute safety to human body.
* Flexible operation: support automatic transmission power and manual mode selection, easy to operate manually
* Friendly Man-machine interface: support OLED visual graphical interface, vivid display of power emission level and second and third harmonic graphics, easy to operate.
* High cost performance: with the world most cost-effective, cost-saving and excellent performance.
| Working Frequency | 2400MHz |
| Working Voltage | 8.4V |
| Frequency Range | 2.404GHz-2.472GHz |
| Receiving 2nd-3rd Harmonic Range | 4.808GHz-4.944GHz; 7.212GHz-7.416GHz |
| Pulse Mode Transmit Power (Max.) | 0-4W (EIRP) |
| Receiving Sensitivity | Less than -140dBm |
| Adjustable Range of Transmitting Power | 0.05-1w |
| Receiving Dynamic Adjustable Range | 30dB |
| Battery Working Time in Maximum Power Pulse Mode | 2H |
| Battery Type | Replaceable Lithium Battery, working time over 4H |
| Charging Time | Fast Charging 2.5H/block |
| Interactive Interface | LED Display Received Harmonic Signal Intensity; |
| Audio Prompts are supported and headphones can be connected; | |
| Supporting Vibration Tips | |
| Detection Distance | GPS Module: 400-500mm |
| Mobile Phone: 180-220mm | |
| Sim Card: 90-120mm | |
| Product Size | 545(L)*170(W)*113mm(H) |
| Outer Box Size | 625(L)*445(W)*230mm(H) |
| Product Weight | 1.6kgs |
| Working Temperature | (-)20 ~(+) 45 degree |
| Working Humidity | No more than 85%, no condensate |
