Brief Introductions:
Type: | Band Saw Blade |
Bond: | Electroplated |
Application: | Polishing, grinding steel, stone, glass, ceramics, mono crystalline silicon, polysilicon, zirconia, alumina, metal-nonmetallic synthetic materials, cemented carbide, aluminum magnesium alloy, aluminum beryllium alloy, titanium alloy and etc. |
Specification: | Customized |
Brand Mark: | Moresuperhard |
Trade Terms: | FOB |
Packages: | Hard carton |
Delivery Time: | 15 workdays by express |
Introductions of Moresuperhard’s Electroplated abrasive belts
Diamond sanding abrasive belt is a kind of coated abrasive tool, which is super hard material (synthetic diamond) abrasive particles adhesive to the flexible base by bond. And can be divided into metal nickel plating electroplated bond and resin bond, resin bond also consists flexible and hard type. In some sense The grinding by diamond sanding belt for thermal spray coating industry can replace that of diamond grinding wheel and film polishing. Diamond sanding belt can complete the grinding and polishing process. Recently, it is widely used in thermal spray coating industry, the production and repair of hydraulic cylinder and turbine blade.
Length | Width | Girt | ||
(mm) | (inch) | (mm) | (inch) | #60,#100,#120, #200, #400, #800, #1500, #2000, #3000, #5000 |
150 – 5000 | 6” – 200” | 5 – 350 | 1/5 “ – 14” | |
Detailed Specifications can be customized!
Advantages of Moresuperhard’s Electroplated abrasive belts
* More embedding depth, less exposure
* Grinding belt does not move parts
* Shortcomings: diamond particles are easy to fall off, do not require grinding allowance.
* Wet grinding effect is good
Examples:
Workpiece diameter | 400mm*12 HVOF spraying |
Grinding machine model | 65656 |
Belt speed | 22 m/s (2800rpm) |
Belt contact workpiece mode | soft contact or hard contact |
Workpiece rotation speed | 30 RPM |
Coolant | water or others |
Spray coating thickness | 250μm |
Original roughness of spray coating | Ra 0.4mm-0.6mm |
Machining allowance of spray coating | 100μm |
Coating thickness after processing | 150μm |
