Brief Introductions:
Type: |
Brazed diamond grinding wheel |
Bond: |
Brazed |
Application: |
Grinding cast iron, marble, ceramic materials, fiber reinforced plastic, silicon carbide and artificial stone. |
Specification: |
Customized |
Brand Mark: |
Moresuperhard |
Trade Terms: |
FOB |
Packages: |
Hard carton |
Delivery Time: |
15 workdays by express |
Introductions of Moresuperhard’s Brazed diamond grinding wheels
Vacuum brazed diamond cup wheels are installed on grinder used for grinding workpieces made of raw metal and steel, especially cast iron, angle iron, ductile iron, carbon steel,etc…
Application of Vacuum Brazed Diamond Grinding Disc
Vacuum brazed diamond grinding disc for grinding cast iron, angle iron, ductile iron, carbon steel, etc.
Model |
Diameter(mm) |
Hole(mm) |
Thickness(mm) |
Vacuum Brazed Diamond Grinding Disc |
100 |
16/22.3 |
1.5-3 |
150 |
16/22.3 |
1.5-3 |
|
|
Grain Size: Rough 25/30, 30/35, 35/40, Finish 50/60 Moresuperhard can support customize service according to your requirement | |||
Detailed Specifications can be customized!
Advantages of Moresuperhard’s Brazed diamond grinding wheels
* Higher quality process than sintered or laser welded diamond wheel
* Long life
* High efficiency
* Single layer of fully exposed diamond fused with nickel at high temperatures and sharp cutting
* No pollution, low noise, never need dressing
