Mitsubishi Q-series PLC basic mode Q00JCPU
Q00JCPU program capacity: 8k steps I/O points: 256 power supply, integrated CPU on the substrate
Mitsubishi Q00JCPU, Q00CPU, and Q01CPU belong to the basic type of QCPU. Q00JCPU is a CPU module with a power module, and its main substrate and CPU module are integrated, so there is no need for a power module and main substrate.
Detailed Specification for Mitsubishi PLC CPU Q00JCPU Product
【 Control Method 】 Sequential Control Program Control Method
[I/O control mode] Refresh mode (when directly accessing I/O (DX □, DY □) through * * *, I/O can be directly accessed)
Program Language
◆ Sequential Control Language: Relay Symbolic Language, Logic Symbolic Language, SEELSAP3 (SFC), MELSAP-L, Function Block and Structured Text (ST)
Processing speed (sequence control program instructions)
◆ LD X0： 200ns
◆ MOV D0 D1 700ns
[Tracking Execution Time (Extended Scan Time)] None
[Constant scanning (function used to maintain normal scanning time)] 1 to 2000ms (can be set in lms)
【 Program capacity 】 8K steps
Memory capacity
◆ Program memory: 58K
Standard ROM: 58K
◆ CPU shared memory: none
【 Substrate expansion level 】 Level 2
[Number of installed modules] 16
【 Number of files stored 】 Program memory/standard ROM: 6 (parameters, intelligent function module parameters, sequence control program, SFC program, software component annotations, and initial values of software components can be stored as one file each)
[Number of allowed writes in standard ROM] 100000 times
2048 points (X/Y0 to 7FF)
[I/O points] 256 points (X/Y0 to FF)
[Direct Link Soft Components] Used to directly access the soft components of the link, * * * used for MELSECNET/H
Intelligent Function Module Software Component: A software component used to directly access the buffer memory of the intelligent function module.
[Latching Range] L0 to 2047 (default) (The locking range can be set for B, F, V, T, ST, C, D, and W.
【 RUN/PAUSE contact 】 A contact can be set in X0 to 7FF for each of RUN and PAUSE.
The allowable instantaneous power failure time varies depending on the type of power module, with a duration of 20ms or less. Varies depending on the type of power module.
【 DC5V internal current consumption 】 0.26A
Boundary dimensions H * W * D [mm] 98 * 245 * 98
Weight 0.66
Q00JCPU power supply specifications
Input power supply: AC 85-264V
Input frequency: 50/60Hz ± 5%
Input voltage distortion factor: within 5%
Input apparent power: 105VA
Impact current: 40A within 8ms
Rated output current of DC5V: 3A
◆ DC5V overcurrent protection: 3.3A or higher
◆ DC5V overvoltage protection: 5.5~6.5V
Efficiency: 65% or higher
Allowable time for instantaneous power failure: within 20ms (100VAC or higher)
◆ Operation indication: LED indication (POWER LED in CPU part: normal: ON (green), error: OFF)
◆ Fuse: built-in (cannot be changed by the user)
◆ Contact output column: None
Terminal screw size: M3.5 * 7
Available wire diameters: 0.75 to 2mm square
Available crimping terminals: RAV1.25 to 3.5, RAV2 to 3.5
