The Stainless Steel Filter Powder Metallurgy

The stainless steel filter is a type of metal porous filter element made from industrial metal powder, typically 304 or 316L. The raw material is formed through cold isostatic pressing and then sintered under high temperature and high vacuum conditions. The resulting filter element contains countless micropores that are curved, criss-crossed, and highly precise, allowing for deep-level precision filtration through pressurization.

The stainless steel filter is a highly advanced type of metal porous filter element that is widely used across many industries, including petrochemical, coal chemical, pharmaceutical, water treatment, food, metallurgical, and gas purification industries.

Product parameters

Outer diameter: Φ20~100mm

Length: 100~1500mm (more than 1500mm can be welded)

Filtration accuracy: 0.5um~50um

Porosity: 35-45%

Features

Here are four key features of the stainless steel filter:

1. Precise and uniform porosity: The stainless steel filter boasts highly accurate and uniform porosity, which ensures precision in filtration. The countless micropores inside the filter are curved, criss-crossed, and highly precise, allowing for deep-level precision filtration through pressurization.

2. Excellent mechanical properties: The filter has excellent mechanical properties, including impact resistance and alternating load. It has a stable shape with low resistance to filtration, enabling high permeability.

3. High-temperature resistance: The stainless steel filter has a high temperature resistance of up to 600℃, making it suitable for use in high-temperature environments. It exhibits a stable separation effect, and its good chemical stability provides high resistance to corrosion at high temperatures.

4. Easy to regenerate: The filter is easy to regenerate, enabling simple reverse cleaning and ensuring an extended service life. It is easy to weld, with seamless welding lengths of up to 1500mm, and the filter is highly versatile, making it suitable for use in a wide variety of applications.

Application

With its unique porous technology, stainless steel filters are widely used across a range of industries, including the petrochemical, coal chemical, pharmaceutical, water treatment, food, metallurgical, and gas purification fields. The filter is a new type of filtration and separation technology material that can be used for various applications, such as terminal filtration of petroleum products, fly ash filtration in the coal chemical industry, impurity removal and filtration of raw materials in the pharmaceutical and chemical industry, water purification, and filtration after ozone sterilization in the water treatment industry, and clarification and filtration of milk, beverages, beer, mineral water, and vegetable oil in the food industry.

Processing:

The production process of stainless steel filters involves monitoring all raw materials, including the metallurgical composition, particle size distribution, and bulk ratio of the metal powder. After being formed through cold isostatic pressing, the filter is sintered at high temperature and high vacuum. Before and after the sintering operation, the carbon content is detected, and each batch of products produced is tested for bubble point, hardness of the medium, and permeability, density, and carbon content of the diameter of spherical particles to ensure high-quality production. The filter is also easy to weld, with seamless welding lengths of up to 1500mm.
