200A/100mA Split current transformer AC Low Voltage CT
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
100A/33.33mA Split current sensor AC China suppliers
-
Acrel AFL-T 500A/75mV DC Current Shunt Class 0.5 Definite Value Shunt for Charging Pile
-
Acrel AFL-T 75ADC/75mV shunt suitable for DC meter
-
Split Current Transformer 3 to 1 with RJ45 port output 200A/20ma
-
small current transformer 20mm aperture split core current transformer 100A/20mA
-
600-1000a small size split core ct AKH-0.66/K K-50 current transformer output 5A or 1A
Product Description
Products Description
AKH-0.66 K-φ24 Splitcore Current Transformer
*Model:AKH-0.66/K-24
*Primary Current: 200A
*Secondary Current: 100mA
*Accuracy: 0.5 Class
*Standard: IEC/EN61869-1, IEC/EN61869-2
Explanation of Model Name
Function & Parameter
Technical Parameters
Model Name | Current Ratio(A) Primary/Secondary | Accuracy Class | Rated Load (VA) | Aperture Hole Diameter(mm) |
AKH-0.66/K-Φ10 | 5A/1.67mA | 0.5 | 10 | φ10 |
5A/2.5mA | 0.5 | 10 | φ10 | |
10A/5mA | 0.5 | 10 | φ10 | |
45~50A/20mA | 0.5 | 10 | φ10 | |
80A/26.7mA | 0.5 | 10 | φ10 | |
AKH-0.66/K-Φ16 | 120A/40mA | 0.5 | 10 | φ16 |
40~100A/20mA | 0.5 | 10 | φ16 | |
80A/32mA | 0.5 | 10 | φ16 | |
AKH-0.66/K-Φ24 | 60~200A/20mA | 0.5 | 10 | φ24 |
200A/40mA | 0.5 | 10 | φ24 | |
200A/100mA | ||||
150~200A/5(1)A | 1 | 1 | φ24 | |
200~300A/5(1)A | 1 | 1.5 | φ24 | |
AKH-0.66/K-Φ36 | 400A/50mA | 0.5 | 10 | φ36 |
400A/40mA | 0.5 | 10 | ||
600A/75mA | 0.5 | 10 | ||
200~400A/20mA | 0.5 | 10 | ||
300~400A/5(1)A | 1 | 1.5 | ||
500~600A/5(1)A | 0.5 | 1.5 |
Dimension & Installation
Dimension Overview
Installation Instruction
Solutions & Applications
Application Scenario
Petrochemical
Siderurgy
Rail Transportation
Contact Us
Acrel Co,.Ltd
Shelly Zhang(Oversea sales manager)
Shelly Zhang(Oversea sales manager)
Email:shelly@acrel.cn
phone:+86 18702111813
WhatsAPP:+86 18702111813
WeChat:+86 18702111813
Address:No,253,Yulv Road,Jiading district,Shanghai,China.
phone:+86 18702111813
WhatsAPP:+86 18702111813
WeChat:+86 18702111813
Address:No,253,Yulv Road,Jiading district,Shanghai,China.
Company Profile
Acrel Co., Ltd. [Stock Code : 300286. SZ] is a high-tech enterprise concentrating on research, production, sales and services. It mainly provides systemic solutions of energy efficiency management and electrical safety for users. ‘Acrel’ is equipped with the complete production lines from cloud platform software to sensors. Until now, it has more than 8000 sets systemic solutions used in China to help users to realize energy visual management ,supply energy data services and improve electrical efficiency and safety. ‘Acrel’ has maintained steady growth since its listing in 2012. The company will adhere to the concept of ‘innovation,high-efficiency,unity and honesty’ and it provides more high-quality solutions,products and service for power system users and micro-grid.
Payment & Delivery
1.Payment: T/T 100% in advance, credit card, western union, in cash and etc. T/T 30% as deposit and the balance before shipment or against copy of B/L is acceptable with enough MOQ.
2.Delivery Arriving Time: in 3-7 working days after payment received.
3.Ways of Delivery: By sea, air, train or international courier like Fedex, TNT, DHL and UPS.
