1、 Product overview:
Arrester discharge counter test rod is designed and developed by relevant technicians of our company according to the needs of power users. The product has beautiful appearance and is easy to carry and use. It replaces the traditional heavy testing instruments and methods and is welcomed by the majority of professionals.
2、 Usage
1. Please charge before use. In order to ensure the charging effect and extend the battery service life, you need to use a special charger. It takes about 2-3 hours for the empty battery to be fully charged. The red light on the charger indicates that it is charging, and the green light indicates that it is fully charged.
2. Pull out the telescopic discharge pole properly according to the installation height of the counter.
3. For the special grounding wire, one end of the plug is inserted into the rear jack of the calibrator, and the other end of the clip is grounded.
4. After each click, the discharge rod end should leave the counter. To repeat the test, press the measurement button once. When the indicator light is on for 1-2 seconds, release the button to click the test again.
5. Continuous testing will cause the calibrator to heat up. Please adjust the clearance time appropriately. To reduce failures and extend battery life.
6. If the indicator does not flash after pressing the button for more than 3 seconds, it indicates that the battery needs to be charged.
7. If the button is pressed but not discharged or the use is completed, please discharge the discharge rod end to the contact point for several seconds when the button is released to ensure user safety.
8. Do not disassemble the calibrator at will. If the capacity of the battery pack decreases significantly or the charging efficiency is too low, it needs to be replaced. Please purchase a special battery pack from our company.
3、 Technical indicators:
1. Telescopic rod: 1.0m
2. Weight: 780g
3. Power supply: DC 3.7V (rechargeable lithium battery)
4. Output voltage: 800~1600V
