Hot Sale Brand New Water-cooled VM D704 Series Diesel Engine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Good Quality VM D704 Series EngineNegotiableMOQ: 1 -
Brand New High Quality Vehicle Engines VM R428(110kw/3800rpm) Diesel EngineNegotiableMOQ: 1
-
VM Diesel Engine VM 2.5 VM R428 DOHCNegotiableMOQ: 1
-
D Series Diesel Motor VM D754 Series EngineNegotiableMOQ: 1
-
4 Cylinders VM D754 Series EngineNegotiableMOQ: 1
| VM D704 Series engine |
| Model | D754G68E2 | D704G82E2 | D754G95E2 |
| Type | Vertical, water-cooled, four-stroke | Vertical, water-cooled, four-stroke, turbocharged | Vertical, water-cooled, four-stroke, turbocharged |
| No.of cylinders-bore×stroke ( mm ) | 4-94 x 107 | 4-94 x 100 | 4-94 x 107 |
| Valves per cylinder | 2 | ||
| Displacement(L) | 2.97 | 2.776 | 2.97 |
| Combustion chamber | Direct injection | ||
| Compression ratio | 18:01 | ||
| Rated output (kW) /Speed (r/min) | 50±5%@2600 | 60.5±5%@3000 | 70±5%@2600 |
| Max.torque (N.m) /Speed ( r/min ) | 210±5%@1400 | 290±5%@1400 | 335±5%@1300 |
| Specific fuel consumption (g/kW.h ) | 235 | 230 | 238 |
| Emission standard | 97/68 EC Stage2 and Tier2 limits | ||
| Fuel injection equipment | Bosch rotary pump | ||
| Camshaft arrangement | into engine block | ||
| Balance shaft | in the oil sump,optional | ||
| Overall dimensions: L×W×H(mm) | 694×518.5×685 | 720×557×736 | 720×557×736 |
| Model | D754G70E3 | D754G81E3 | D754G95E3 |
| Type | Vertical, water-cooled, four-stroke | Vertical, water-cooled, four-stroke, turbocharged | Vertical, water-cooled, four-stroke, turbocharged and intercooled |
| No.of cylinders-bore×stroke ( mm ) | 4-94 x 107 | 4-94 x 107 | 4-94 x 107 |
| Valves per cylinder | 2 | ||
| Displacement(L) | 2.97 | 2.97 | 2.97 |
| Combustion chamber | Direct injection | ||
| Compression ratio | 18:01 | ||
| Rated output (kW) /Speed (r/min) | 51,5±5%@2600 | 59.8±5%@2600 | 70±5%@2600 |
| Max.torque (N.m) /Speed ( r/min ) | 250±5%@1800 | 274±5%@1800 | 420±5%@1000 |
| Specific fuel consumption (g/kW.h ) | 235 | 233 | 231 |
| Emission standard | 97/68 EC Stage3A and Tier3 limits | ||
| Fuel injection equipment | Bosch rotary pump | ||
| Camshaft location | in-block | ||
| Balance shaft | in the oil sump,optional | ||
| Overall dimensions: L×W×H(mm) | 720×546×687 | 720×508×740 | 720×508×736, |
