Home > Products > INDUSTRY LASER EQUIPMENT > High Configuration Fiber Laser Cutting Machine WMT-1530G for Sheet Metal Cutting

Share|

High Configuration Fiber Laser Cutting Machine WMT-1530G for Sheet Metal Cutting

Name: High Configuration Fiber Laser Cutting Machine WMT-1530G for Sheet Metal Cutting
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Fiber Laser Cutting Machine WMT-1530G Main Features:

Fiber laser specially cutting middle thick and thin materials such as stainless steel, mild steel/carbon steel, copper, alloy steel, spring steel, galvanized plate, etc. Applicable fields: aviation, aerospace, electronics, appliances, subway accessories, automobile,machinery, precision parts, ships, saw blades, elevators, craft gifts, decoration, advertising...

1. Enclosed type, with exchange table;

2. Professional laser source Raycus, best brand in China; 3. Raytools auto-focus cutting head BM114;

4. Heat treated thick plate welding machine bed;

5. Aviation aluminium gantry;

6. Taiwan,China HIWIN guide rail;

7. Taiwan,China YYC gear rack;

8. X,Y,Z axis Japan Fuji servo motor;

9. France Motoreducer;

10. France Schneider electrical components;

11. Professional FSCUT2000S control system with Cypcut software;

12. Automatic lubrication system;

13. Dual-temperature HanLi/S&A cooling system.

Fiber Laser Cutting Machine	WMT-1530G
Working area	1500mm*3000mm
X-axis route	1530mm
Y-axis route	3050mm
Z-axis route	320mm
Running speed	140m/min
Biggest acceleration	1.5G
XY axis positioning accuracy	0.03mm
XY axis repeated positioning accuracy	0.02mm
Machine noise	﹤75db
Operating Voltage	380V ±5% 60Hz Three-phase
Overall power distribution	Around 29.8KW
Machine dimensions	8400×2930×2300mm

Detailed Images

Company Profile

FAQ

Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.

Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3: Do you have a stock?
A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4: What’s the MOQ?
A4 :One set only.

Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6: Do you have professional engineers?
A6: Yes.we have professional engineers and designers. We can provide OEM services.

Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.

Company Profile

Jingjiang Fuji Technology Co., Ltd.

Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
