Product Description
Roti Production Line
Introduction Information of Roti Production Line
Automatic roti production line the multifunctional equipment which can produce flat bread, pita bread, tortilla, arabic bread, pizza crust, samosa wrapper etc.The pitta bread making machine, compared with the manual operation has the characteristics of
High efficiency, low noise, save labor and time.We accept customized product according to customers’ requirements.Pita Bread Production Line includes dough mixer, dough sheeter, pita bread maker and pita oven.
Working Procedure of Roti Production Line
Dough Mixer
Operation Method:
1.Turn on the power supply, switch on, starting up to make the machine run normally;
2.Put the flour and other materials and water into the dough bucket to stir, after stirring to the requirement, pull out the plug, tilt the bucket down 90 degrees and pour out dough.
TZ25 | TZ50 | TZ75 | |
Capacity | 250kg/h | 400kg/h | 450kg/h |
Motor Power | 2.2kw/380v | 3kw/380v | 4kw/380v |
Weight of Machine | 100kg | 150kg | 170kg |
Dimension | 850*650*900 | 1050*680*950 | 1130*720*1150 |
Dough Sheeter
Operation Method:
1.Check whether the fasteners are loose before use. Turn on the power, rotate 5-10 minutes according to the arrow on the belt guard.
2.Sprinkle the flour on the dough at the entrance. Adjust the upper and lower roll gaps to roll the dough between the two rolls.
3.The dough is rotated and repeated several times until the desired hardness of the dough is reached.The thickness of the dough can be adjusted.
4. After each use, the machine should be cleaned, the edible oil should be coated on the surface of the roller.
Model | TZ350 | TZ500 |
Width of dough roller | 350mm | 480mm |
Capacity | 350kg/h | 500kg/h |
Power | 3kw | 4kw |
Weight of Machine | 250kg | 300kg |
Dimension | 1330*615*1060 | 1350*755*1240 |
Pita Bread Maker
Put the dough wrapper into the hopper, roll it through roller, and convey it from the conveyor belt. The powder box sprinkles flour on the dough, and then formed by the mold roll. The scrap is transferred from the belt to the original hopper.
Model | TZ160 | TZ220 | TZ330 | TZM380 | TZM500 |
Width of dough wrapper | 160mm | 220mm | 330mm | 380mm | 500mm |
Speed | 70-100piece/minutes | 140-200piece/minutes | 210-300piece/minutes | 1000piece/h | 17-200piece/h |
Motor Power | 2.2kw/220v | 3kw/220v | 3kw/220v | 3kw 220/380v | 3kw 220v/380v |
Weight of Machine | 220kg | 260kg | 330kg | 280kg | 900kg |
Dimension | 1200*560*1200 | 1200*620*1200 | 1200*730*1200 | 1700*780*1200 | 4300*900*1550 |
Pita Tunnel Oven
Conveyor the dough wrapper formed by mold to the oven, it is roasted in the tunnel uniformly. The oven can be customized to two layers, three layers to make sure two sides of dough wrapper will be oven well.
Model | TZ-1 |
Power | 1.2kw |
Voltage | 220v/50HZ |
Weight | 560kg |
Dimension | 2750×930×1200mm |
We can deliver the goods to you by sea, by air, by express or by land transportation. We will try my best to make you get the goods faster and safe.
Zhengzhou Taizy Machinery Co. Ltd in Zhengzhou is a large scale industrial group mainly
specialized in the food processing machines, covers Fryer Machinery, Fruits and vegetables
processing Machine, Paste Processing Machinery, Meat Processing Machinery, Nut Processing
Machinery. With years of manufacturing and Sales experience in the machinery industry, let
customer satisfied is our ultimate aim, we got good fame for providing high-quality machines
and best service concept - quality first, service foremost.
1. How long will the transportation take?
Depending on your quantity, for goods, we have in stock. Delivery takes a few days to comply with your request to replace the plug or other configurations. For regular order, by ocean shipping takes 20-40 days. For small machines, express delivery for 3-8 days.
2. Are you a manufacturer or distributor?
We are an experienced manufacturer and exporter. We own a technical team comprised of over-average experts in R&D and innovation. Notably, we own high-level factories and cooperating factories who can offer efficient manufacturing and high-end products when dealing with a bulk order.
3. How do I know about the details and quality of your machine?
First, we have product brochures covering all details including parameter, material, output, etc. of most of our production lines; secondly, we can provide you with videos filmed on-site with details about the working process and how mechanical parts work during operation; at last, you are warmly welcomed for on-site inspection at our factories.
4. What certification do you have?
We have ISO, CE, BV, SGS, TUV etc. Please do trust us, we are determined to provide you the best quality equipment.
5. Why choose us?
We have dedicated to the machinery manufactory industry for more than 10 years with a rare negative response. We are time has proven-- client’s response and comments are the most validated evidence.
