XCLP2 Hydraulic Press Cutting Machine
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
- Blister Cutting Machine
- XCLP3-C Precision Hydraulic 4-column Die Cutting Machine for Leather, EVA and Rubber
- Automatic Hydraulic EVA Die Cutting Machine for Gasket, Jigsaw Puzzle
- Roll to Roll Denim Fabric Inspection Machinery
- factory hot sales woven fabric rolling inspection machine
- High Quality Fabric Inspection Cum Winding Machine
Product Description
Hydraulic Press Machine
Hydraulic Press Cutting Machine
XCLP2 HYDRAULIC 4-COLUMN PLANE CUTTING MACHINE
Brazil Type Die Cutting Machine
Hydraulic Press Machine - Product Description
Application:
- This type of hydraulic press machine is widely used for cutting EVA, foam, fabric, cardboard, rubber, sponge, bag materials, nonwoven and many other non-metallic materials in various industries;
- This hydraulic press machine is good at cutting foam products, jigsaw puzzle, shoe materials and other products.
Main Features:
- The machine body is made of high quality materials. It is very strong and durable.
- Integrated and reasonable mechanical, hydraulic and electrical design makes the cutting machine easy to operate.
- Good hydraulic drive mode and high quality hydraulic system components lower the machine running noise. The hydraulic system will supply oil for the lubrication of all the sliding parts of the machine. Therefore, the machine has longer service life.
- Precise 4 column machine structure and double connecting bar make the machine run in a balanced and stable way. The auto slowdown setup of the upper pressing board keeps the same cutting depth in the overall cutting area.
- The motor oil pump is put outside, creating for the machine good ventilation and cooling conditions. The operation is safer and the machine can be used for a longer time, because without the heating source, the oil temp is lower and oil seal will have a longer life.
- It is easy and convenient to install and set the cutting mould or die.
- Different materials feeding systems such as auto clamp feeding, conveyor belt feeding and feeding sliding board can be installed as per customers' specific requirements.
- Low maintenance cost and energy saving.
- Other features can be added on request.
Reference Technical Data ( Customizable):
Model | XCLP2-300 | XCLP2-350 |
Rated Cutting Force | 30T | 35T |
Stroke Range | 5-125mm | 5-125mm |
Distance between Upper and Lower Tables | 55-180mm | 55-180mm |
Pressing Board Effective Area | 1600X600mm | 1600x700mm |
Working Table Effective Area | 1600X620mm | 1600X720mm |
Motor Power | 2.2kw | 3.0kw |
Estimated Machine Dimension | 2340X700X1520mm | 2340X850X1520mm |
Estimated Machine Weight | 2000kg | 2300kg |
Hydraulic Press Machine
Hydraulic Press Machine with Conveyor Belt
Hydraulic Press Machine with Auto Feeding Sliding Boards
Packaging & Shipping
Hydraulic Press Machine
Inner Package: Protective Film, etc
Outside Package: Plywood Case
- Machines well packed with protective film and loaded in plywood case or export container;
- English version operation manual and technical data;
- One-Year-Period wear parts;
- Tool kit
Our Services
Engineers Onsite Installation and Operation Training
Company Information
Hydraulic press machines of various typies are available on request!
