Home > Products > Lathe Turret > Factory Direct Sale 4 6 8 Stations SLT Series Servo Automatic Turret for Cnc Lathe Tool Turret
Factory Direct Sale 4 6 8 Stations SLT Series Servo Automatic Turret for Cnc Lathe Tool Turret
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Three Gear-teeth Location BWD Series Hydraulic CNC Lathe Quick Change Tool Post
-
Factory Direct Sale SLTA Series Hydraulic Turret Tool Post CNC Lathe Part Turret
-
High Precision 8 Stations SLTR Series Radial Servo Power Tooling Cnc Turret
-
CNC Lathe Usd Quick Change Tool Turret 8/12 Position Tool Holder SLT Series Power Servo Turret
-
CLT Series 6/8 Position Powerful Hydraulic Motor Cnc Lathe Tool Turret for Cnc Machine in Stock
-
BWD Series Quick Change Tool Holder Turret for Cnc Lathe Power Turret Cheaper 6 Position
Product Description
Product Description
Item | Unit | Model | ||||
SLT63 | SLT80 | SLT100 | ||||
Center height | mm | 63 | 80 | 100 | ||
Allowed number of tools | 8;12 | 8;12 | 8;12 | |||
Time for 45°ratation and clamping | sec. | 0.23 | 0.35 | 0.42 | ||
Time for 180°ratation and clamping | sec. | 0.55 | 0.76 | 0.83 | ||
Clamping force | kg | 1700 | 2600 | 3500 | ||
Hydraulic working pressure | MPa | 3.5±0.5 | 3.5±0.5 | 3.5±0.5 | ||
Flow rate | L/min | 18 | 20 | 25 | ||
Indexing accuracy | ±4" | ±4" | ±4" | |||
Accuracy of repeatability | ±1.6" | ±1.6" | ±1.6" | |||
Net weight (Without tool disc) | kg | 50 | 68 | 88 | ||
Model | Dimension | ||||||||||||||||
H | A | B | C | D | E | F | H1 | K | |||||||||
SLT63 | 63 | 20 | 8-φ11 | 22 | 135 | 65 | 380 | 225 | 20 | ||||||||
SLT80 | 80 | 25 | 8-φ11 | 23 | 140 | 80 | 390 | 260 | 25 | ||||||||
SLT100 | 100 | 30 | 8-φ13 | 30 | 170 | 90 | 400 | 300 | 25 | ||||||||
M1 | M2 | O | Q | R | S | T | U | V | |||||||||
SLT63 | PT1/4 | PT1/4 | 228 | 172 | 24 | 30 | 30 | 15 | 165 | ||||||||
SLT80 | PT1/4 | PT1/4 | 270 | 195 | 25 | 32 | 32 | 17 | 190 | ||||||||
SLT100 | PT1/4 | PT3/8 | 330 | 240 | 34 | 40 | 30 | 20 | 220 | ||||||||
W | X | ||||||||||||||||
SLT63 | 185 | 7.5 | |||||||||||||||
SLT80 | 210 | 7.5 | |||||||||||||||
SLT100 | 250 | 9 | |||||||||||||||
Other Products
FAQ
Q: How long is the quality guarantee?
A: One year guarantee.
Q: How long is the delivery time?
A: Generally it is 3-7 days if the goods are in stock. If the goods are not in stock, it will take 8-20 days.
Q: Do your products have a factory inspection before shipment?
A: 100% self-inspection before shipment.
Q: Can you provide some free samples?
A: Actually we have a very good price principle, when you make the bulk order then cost of sample will be return to you.
Q: What kind of packing do you send?
A: We use high quality cartons, internal environmental protection buffer material.
Q: What is our loading port?
A: Usually in Shanghai port, or apply for other ports.
A: One year guarantee.
Q: How long is the delivery time?
A: Generally it is 3-7 days if the goods are in stock. If the goods are not in stock, it will take 8-20 days.
Q: Do your products have a factory inspection before shipment?
A: 100% self-inspection before shipment.
Q: Can you provide some free samples?
A: Actually we have a very good price principle, when you make the bulk order then cost of sample will be return to you.
Q: What kind of packing do you send?
A: We use high quality cartons, internal environmental protection buffer material.
Q: What is our loading port?
A: Usually in Shanghai port, or apply for other ports.
