High Quality CNC Milling Machine 3 Axis Vertical Machining Center VMC 855
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2014
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Milling Center Cnc Vertical Machining 1270BL CNC Vertical Machining Center LJ-L1270NegotiableMOQ: 1 -
High Quality 3 Axis CNC Vertical Machining Center VMC 855 for MetalNegotiableMOQ: 1
-
Precision Cnc Machining Center VMC 850 Vertical Milling MachineNegotiableMOQ: 1
-
New Design CNC Machine Center VMC1580 VMC1580A Vertical Milling Machining Center in StockNegotiableMOQ: 1
-
LJ855 Series CNC Milling Machine High Precision Controller Cnc Vertical Milling CenterNegotiableMOQ: 1
Product Description
Specification
ITEM |
VMC855 |
WORKTABLE SIZE (L×W) (MM) |
1000*550 |
MAX. X AXIS TRAVEL (MM) |
800 |
MAX. Y AXIS TRAVE (MM) |
550 |
MAX. Z AXIS TRAVEL (MM) |
550 |
RANGE OF SPINDLE NOSE TO WORKTABLE |
120-670 |
DISTANCE FROM SPINDLE CENTER TO COLUMN (MM) |
590 |
WORKTABLE SPACINGOF T-SLOTS (NUMBER-SIZE×DISTANCE) |
5-18*90 |
SPINDLE (MODEL /DIAMETER) |
BT40/Φ150 |
SPINDLE SPEED |
8000RPM(BELT/DIRECT) |
X.Y.Z AXIS BALL SCREW |
4016 |
TRACK WIDTH (X/Y/Z) |
35/45/45 |
SCREW DIAMETER |
40/40/40
PITCH 16MM
|
X.Y.Z AXIS RAPID SPEED (MM/MIN) |
X48000/Y48000/Z48000 |
X.Y.Z AXIS SPEED (MM/MIN) |
1-10000 |
X AXIS LINEAR SPECIFICATION |
RGH35HA |
Y AXIS LINEAR SPECIFICATION |
RGW45HC |
Z AXIS LINEAR SPECIFICATION |
RGW45HC |
XYZ AXIS MOTOR CONNECT WAY |
DIRECT |
RECOMMEND SPINDLE MOTOR POWER (KW) |
7.5KW |
STANDARD SYSTEM |
SIEMENS/FUNUC |
RECOMMEND X.Y.Z AXIS MOTOR (NM) |
11/11/20(brake)
B12/B12/B22(brake)
|
TOOL SHANK MODE |
BT40 |
TOOL MAGAZINE |
ATC ARM TYPE |
TOOL MAGAZINECAPACITY(PCS) |
24T |
TOOL CHANGING TIME(S) |
1.75 |
BED CUSHION HEIGHT |
50MM |
X/Y/Z POSITIONING ACCURACY(MM) |
±0.005/300JIS |
X/Y/Z REPEAT POSITIONING ACCURACY(MM) |
±0.003/300JIS |
MAX LOADING OF WORKTABLE (KG) |
500 |
FRAME MATERIAL |
HT300 |
SPINDLE |
TAIWAN BRAND |
SCREW |
TAIWAN BRAND |
LINEAR |
TAIWAN BRAND |
BEARING |
JAPAN |
TOOL CHANGER |
TAIWAN BRAND |
DIMENSION (MM) |
2603*2360*2455 |
FRAME WEIGHT(KG) |
3400 |
MACHINE WEIGHT (KG) |
5000 |
Company Profile
Wuxi Fagor Technology Co.,Ltd.is specialized in CNC machine tools accessories .The main products of our company are 4 axis rotary table,5 axis rotary table,water pump, chuck, coupling, end mill grinder,chipping machine,cutter barrel,three-color lamp,knife tower and other accessories With high precision and full varieties are deeply trusted and appreciated by customers.At the same time we have a strong sales team and experienced core service team.we are ready to provide CNC machine tool accessories one-stop solution for you,looking forward to cooperating with you and going to a win-win situation
FAQ
Q: How long is the quality guarantee?
A: One year guarantee.
Q: How long is the delivery time?
A: Generally it is 3-7 days if the goods are in stock. If the goods are not in stock, it will take 8-20 days.
Q: Do your products have a factory inspection before shipment?
A: 100% self-inspection before shipment.
Q: Can you provide some free samples?
A: Actually we have a very good price principle, when you make the bulk order then cost of sample will be return to you.
Q: What kind of packing do you send?
A: We use high quality cartons, internal environmental protection buffer material.
Q: What is our loading port?
A: Usually in Shanghai port,or apply for other ports.
