Kitchen Grease Ventilation Robotic Duct Cleaning Machine

Kitchen Grease Ventilation Robotic Duct Cleaning Machine photo-1
Kitchen Grease Ventilation Robotic Duct Cleaning Machine photo-2
Kitchen Grease Ventilation Robotic Duct Cleaning Machine photo-3
Kitchen Grease Ventilation Robotic Duct Cleaning Machine photo-4
Kitchen Grease Ventilation Robotic Duct Cleaning Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
1999
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Kitchen grease ventilation robotic duct cleaning machine




PC-100 grease cleaning equipment is used for cleaning kitchen or restaurant oil fume.

It matches with high pressure hot water jet machine to clean heavy oil.

Features:

1. With camerasvideo recording system and smart control box.
2. High-pressure nozzle can do
360° unlimited rotation, also up and down swing, spray direction without dead ends
3. Walking speed: 0 ~ 12 m / min stepless speed regulation
4. Strong permanent magnet
magnetic crawler, can clean vertical duct)

 Kitchen grease ventilation robotic duct cleaning machine

PC-100 GREASE CLEANING MACHINE
Dimension
330mm(L)*270mm(W)* 200mm(H)
Weight
 10Kg
Power
120W
Operating stroke
Standard 20 meters (waterproof cable), can be extended to 100 meters
Rotation radius
zero radius (360 ° rotation in situ)
Traveling speed
0--10m / min (stepless speed regulation)
Camera and lighting
520 line industrial color camera, can automatically 360 ° / tilt 90 ° rotation
IP66Waterproof
IP66
Cameras
2

 Kitchen grease ventilation robotic duct cleaning machineKitchen grease ventilation robotic duct cleaning machine

Smart control box
Material
aluminum alloy
working voltage
AC 220V/50Hz (or as your needed)
Video recording
MP4
Power
150W
Working voltage
DC 24V
LCD monitor
10.4′
Weight
12kg
Size
450*350*220mm

Kitchen grease ventilation robotic duct cleaning machine



Matched high pressure hot water jet machine
Maximum water temperature
80-120℃
Water flow (adjustable)
540L / H
Water pressure (adjustable)
140bar
Power
2.2kw
Heating time
40 seconds
Pump speed
1450 rev / min

Kitchen grease ventilation robotic duct cleaning machine

Packing:Kitchen grease ventilation robotic duct cleaning machine



We are professional for ventilation and kitchen duct cleaning.
